Variable Step-Length Efficiency Optimum Control of Traveling Wave Ultrasonic Motor System

Abstract:

To achieve the operational efficiency maximization of ultrasonic motor system, this paper analyzes optimum control of the ultrasonic motor system’s efficiency including driving circuit, while the speed closed-loop control performance is ensured. Based on regulating characteristics of open-loop speed control and fuzzy control, two optimum control methods for regulating the changing step-length of driving voltage amplitude, to shorten the elapsed time of efficiency optimization process and to improve the general operational efficiency of motor system and the speed closed-loop control performance, are also analyzed. The effectiveness of the methods mentioned in this paper are reflected using experiments.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6484-6489
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6484
• Online since: November 2011
• Authors: Bo Liu, Jing Zhuo Shi, Xun Liu
• Keywords: Optimum Control, System Efficiency, Ultrasonic Motor

References

[1] Chen Weishan, Shi Shengjun, Liu Yingxiang and Li Pei, A new traveling wave ultrasonic motor using thick ring stator with nested PZT excitation,. IEEE Trans. on Ultrasonics, Ferroelectrics and Frequency Control, vol. 57, 2010, pp.1160-1168.

DOI: 10.1109/tuffc.2010.1528

[2] Zhu Hua, Li Zhirong and Zhao Chunsheng, An efficient approach to optimize the vibration mode of bar-type ultrasonic motors,. Ultrasonics, vol. 50, 2010, pp.491-495.

DOI: 10.1016/j.ultras.2009.10.010

[3] T. Senjyu, S. Yokoda, K. Uezato, A Study on High-Efficiency Drive of Ultrasonic Motors,. Electric Power Components and Systems, vol. 29, 2001, pp.179-189.

DOI: 10.1080/153250001300006617

[4] T. Ishii, S. Maeno, K. Nakamura and S. Ueha, Efficiency improvement of the friction drive in the ultrasonic motor using lubricant,. Proc. IEEE Symp. Ultrasonic, IEEE Press, vol. 1, 2001, pp.521-524.

DOI: 10.1109/ultsym.2001.991676

[5] Youguang Li and Zaili Chen, Phase shifted ZVT-PWM high-frequency full-bridge inverter with auxiliary resonant nets for driving ultrasonic motor,. Proc. 8th International Conf. on Electrical Machines and Systems, IEEE Press, 2005, pp.1847-1850.

DOI: 10.1109/icems.2005.202881

[6] Wang Haiyan and Shi Jingzhuo, Ultrasonic motor's phase-shift PWM control based on CPLD,. Electrical Automation, vol. 31, 2009, pp.48-50(in Chinese).
