The Hysteretic Behavior of Fiber Beam Element Model of Reinforced Concrete for Dynamic Explicit Analysis

Abstract:

Aim of this paper is to present a numerical method for modeling of the so-called “equivalent box section fiber beam concrete element”. By comparing hysteresis curves of specimen of the concrete structure plotted with rebar beam with those plotted with the equivalent box section beam under a set of loading cases, the following conclusions are obtained: 1) The modeling technology of equivalent box section beam can overcome the difficulty which the rebar in beam can only be used in static calculation, and the fiber beam element can be applied to dynamic explicit analysis; 2) By comparing hysteresis curves which are plotted by the rebar beam with those obtained with model of equivalent box section beam, it is found that results are in good agreement for a specific typical loading case; 3) By comparing hysteresis curves of the equivalent box section beam with experimental data under given loading case, numerical results indicate that numerical results obtained with proposed modeling technology can fit the experiment phenomena very well.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6663-6668
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6663
• Online since: November 2011
• Authors: Xian He Du, Xin Pu Shen, Sheng Ji Jin
• Keywords: Dynamic Explicit, Fiber Beam Element, Finite Element Method (FEM), Hysteresis Curve, Reinforced Concrete (RC)

References

[1] P. Xu. The Complex Structural Design of Tall Buildings,. Beijing: China Building Industry Press, (2005).

[2] H. Zhang. The analysis of onsidering the damage of reinforced concrete structures Object-oriented finite element, Dalian: Dalian University of Technology, (2004).

[3] X. Wang, X. Lu and L. Ye, Numerical Simulation for the Hysteresis Behavior of RC Columns under Cyclic Loads, 12th, vol. 24. Engineering Mechanics, 2007, pp.76-81.

[4] J. Teng, X. Wang, Z. Li, Q. Chen and X. Wang, The Elasto-plasticity Static and Dynamic Analysis of Complex High-level Structure under the Earthquake, 1st, vol. 4. Shenzhen Civil Engineering and Architecture, 2007, pp.22-26.

[5] Spacone E, Fillippou F C, Taucer F. Fiber Beam-Column Model for Non-liner Analysis of RC Frames I. Formulation. International Journal of Earthquake Engineering and Structural Dynamics, (1996).

DOI: 10.1002/(sici)1096-9845(199607)25:7<711::aid-eqe576>3.0.co;2-9

[6] Abaqus Analysis User's Manual. Version 6. 5.

[7] Z. Zhuang, X. You, J. Liao, S. Cen, X. Shen and M. Liang. Finite Element Analysis and Application based on ABAQUS,. Beijing: Tsinghua University Press, (2009).

[8] X. Lu, L. Ye and Z. Liao, Elasto-plastic Analysis of Buildings against earthquake-theory, model and implementation on ABAQUS, MSC. MARC and SAP2000, Beijing: China Building Industry Press, (2009).
