Research on Permanent Magnet Linear Motor without Friction Feed

Abstract:

In order to eliminate the friction of the feed system in NC Machine Tools, this paper presented a novel direct magnetic levitation permanent magnet linear motor. First, the structure and magnetic levitation theory of the direct magnetic levitation motor were discussed. Second, on the basis of the motor magnetic hierarchical model, the expression of the magnetic field and the electromagnetic force was derived by the virtual displacement method. Finally, no-load magnetic field, load air-gap flux density and the electromagnetic force of the motor were simulated by using Ansoft Maxwell 2D software. The results of simulation test indicated that using direct magnetic levitation permanent magnet linear synchronous motor can realize the friction-free feed of NC Machine Tools.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 681-686
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.681
• Online since: November 2011
• Authors: Yi Peng Lan, Hui Zhao, Hong Xuan Lan
• Keywords: Direct Magnetic Levitation, Double-Windings, Friction-Free Feed, NC Machine Tool, Permanent Magnet Linear Motor (PMLM)

References

[1] Rafael Becerril Arreola, Nonlinear control design for a magnetic levitation system [D]. Canada: Graduate Department of Electrical and Computer Engineering University of Toronto, 2003, pp.25-34.

[2] Yang Junyou, Speed tracking control for permanent magnet linear synchronous motor with sliding mode and back-stepping. Journal of Shenyang University of Technology, 2009, 31(6): 601-605.

[3] Du yumei, Shi Liming, Jin Nengqiang, Analysis of the three- dimension forces in a hybrid maglev vehicle system [C]. Proceedings of ICEMS 2003, Beijing, 2003: 563-565.

[4] Lu qinfen, Research on the characteristics of linear synchronous motor [D]. Hangzhou: Zhejiang University, (2005).

[5] Ye yuanyue, The principle and application of linear motors [M]. Beijing: China Machine Press, (2000).

[6] Guo Liang, Chen Benyong, A study on force characteristics of precision magnetic levitation stage [J]. Chinese Society of Electrical Engineering, 2008, 28(21): 118-122.

[7] Shangguan Xuanfeng, Li Qingfu, Yuan Shiying, The vertical hoist system driven by PMLSM with multi-segment primary [J]. Chinese Society of Electrical Engineering, 2007, 27(18): 7-12.

[8] Lu Qinfen, Ye Yunyue, Magnetic field and thrust of hybrid excitation linear synchronous motor [J]. Chinese Society of Electrical Engineering, 2005, 25(10): 127-130.

[9] Chen Youping, Zhang Ying, et al, Analyse and experimental research of magnetic field and thrust fluctuation of permanent magnet linear synchronous motors [J]. Micromotors Servo Technique, 2007, 40(8): 4-8.

[10] Chen Yuming, Jin Nengqiang, Characteristic analysis of electromagnetic field and force for linear synchronous motor [J], Advanced technology of electrical engineering and energy, 2002, vol. 21, no. 1, pp.26-28.
