Effect of Temperature on Electricity Generation of Single-Chamber Microbial Fuel Cells with Proton Exchange Membrane

Abstract:

The effects of temperature on electricity performance and microbial activity were investigated in single-chamber microbial fuel cell with proton exchange membrane (S-PEM-MFC) using glucose as substrate with phosphate buffer solution(PBS). The results showed that S-PEM-MFC able to adapt to a wide temperature range of 11, 18, 25, 30 and 35°C. The open circuit voltage, polarization, power density and microbial activity of S-PEM-MFC were increased with increasing temperature from 11 to 30°C. The maximum power density were 193.8mW∙m-3 at 30°C. Compared to 30°C, the battery open circuit voltage increased by only 4.8% at 35°C, while the polarization and power density is almost the same. These results demonstrate that according to the principle of economy which 30°C should be the optimal operating temperature of S-PEM-MFC.

You might also be interested in these eBooks

Biotechnology, Chemical and Materials Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 393-395)

Pages:

1169-1172

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.393-395.1169

Citation:

Cite this paper

Online since:

November 2011

Authors:

Yu Lan Tang, Ya Ting He, Peng Fei Yu, Hong Sun, Jin Xiang Fu

Keywords:

Microbial Activity, Microbial Fuel Cell (MFC), Temperature

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] B.E. Logan: Environmental Science and Technology. Vol. 1(2006), p.5172.

Google Scholar

[2] K. Watanabe: Journal of Bioscience and Bioengineering. Vol. 106(2008), p.528.

Google Scholar

[3] B.E. Logan: Microbial fuel cells (Trans Tech Publications, beijing 2009).

Google Scholar

[4] G.S. Jadhav and M.M. Ghangrekar: Bioresource Technology. Vol. 100(2009), p.717.

Google Scholar

[5] X. Wang, Y.J. Feng, Y.P. Qu et al: Environmental Science. Vol. 29(2008), p.3128.

Google Scholar

[6] L.B. Zhang, C. Li, L.L. Ding et al: Environmental Pollution and Control. Vol. 32(2010), p.62.

Google Scholar

[7] Y.L. Tang, X.W. Bi, H. Sun et al: Advanced Materrials Research. Vol. 156-157(2011), p.742.

Google Scholar

[8] C.S. Zhou and J. Yin: ACTA Scientiae Circumstantiae. Vol. 16(1996), p.400.

Google Scholar

[9] R.P. Ramasamy and Z.Y. Ren: Biotechnology and Bioengineering. Vol. 100(2008), p.101.

Google Scholar

[10] Y.L. Zhan, Q. Wang, P.P. Zhang et al: Chemical Journal of Chinese Universities. Vol. 2(2008), p.144.

Google Scholar

[11] P. Liang, M.Z. Fan, X.X. Cao et al: Environmental Science. Vol. 28(2007), p.1894.

Google Scholar

[12] B. Min, O.B. Roman and I. Angelidaki: Biotechnol Lett. Vol. 30(2008), p.1213.

Google Scholar

[13] S.A. Cheng, D.F. Xing and B.E. Logan: Biosensors and Bioelectronics. Vol. 26(2011), p. (1913).

Google Scholar
