The Influences of Main Ingredients of the Reclaimed Water on Calcium Carbonate Scale in Recycling Cooling System

Abstract:

The main risk of reclaimed water reused in industry is to control fouling. The main ingredients in reclaimed water form the chemical scale which is one of the main components of the fouling in the recycling cooling system. The main chemical scale of reclaimed water is carbonate scale (calcite). In this paper, by using the actual reclaimed water which reused as make-up water in Beijing Thermal Power Plant to simulate the 4 times concentrate ratio recycling water to study the influence of main ingredients of reclaimed water such as pH，soluble silica, the most content of anions and cations on carbonate scale. The experimental results show that pH, soluble silica, calcium ion and alkalinity have greater influence on scale inhibition, but magnesium ion, chloride ion and sulfate ion have smaller influence on scale inhibition.

• Periodical: Advanced Materials Research (Volumes 393-395)
• Pages: 1554-1557
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.393-395.1554
• Online since: November 2011
• Authors: Guan Hua Yue, Li Min Shang, Li Ping Wang, Li Li Feng
• Keywords: Calcium Carbonate Scale, Reclaimed Water, Scale Inhibition, Water Ingredients

References

[1] Yu Qiyi, Zhang Qing, Gu Xiaohong. Study on the reusing municipal wastewater as recycling cooling water. Recycling research, 2002 (1): 31-34(in Chinese).

[2] Wu Dongwen, Liu Zhengxiu. Using Minicicipal Recycled Water in Cycling Cooling Water System of Coal Burning Power Plant. NORTH CHINA ELECTRIC POWER, 2009(4): 31-34(in Chinese).

[3] Song Xiaohong, Wang Ping. Discussion on problems of treated municipal waste water used as circulated cooling water. Electric Power Environmental Protection, 2006, 22(5): 40-42(in Chinese).

[4] Liu Zhengxiu. Application of urban reused water in circulating cooling water system. Electric power science and engineering, 2008, 24(6): 19-22(in Chinese).

[5] Zhou Bensheng. Chemical solutions of controlling the scale in recirculating cooling water systems. Chemical engineering & machnery, 1999, 26(3): 179-182.

[6] Yue Guanhua, Zhou Hongyun, Zhang Yajun. Countermeasures to Prevent and Cure the Fouling in Recirculing Cooling Water Systems. MSE -2010. 10: 418-422.

[7] L Dubin. Master. Perform. 1985, 24(10): 27-33.

[8] Ye Desen, Silicon scale and scale inhibitor, Industrial Water Treatment. vol. 14, 1994. No. 3: 3-6.

[9] Zou Hongyun, Yue Guanhua. Contrast Study on Scale Formation of Reclaimed Water and Surface Water used As Recycling Cooling Water. CETCE-2011. 4: 6503-6507.

DOI: 10.1109/icetce.2011.5776226

[10] Shengliu Yang, Influence of the ratio of calcium and magnesium to scale and corrosion in recycling water system. Water treatment information reports, 2004(3): 17-18 (in Chinese).

[11] Pytkowicz R M. Geology, 1965, 73: 196.

[12] Bischoff J L. J Geology Research, 1968, 73: 3315.

[13] Epstein N. Proceed 6th Int Heat Transfer Conf. 1978, 4: 235.

[14] D.R. Lide. CRC Handbook of Chemistry and Physics, 71st ed. CRC Press, Inc, 1990～1991: 8-39.
