Influence of Fe₂O₃ on Molten Slag Properties in Slag Splashing on Nickel Smelting Converter

Abstract:

To predict the effect of Fe₂O₃ on slag splashing properties in the nickel smelting converter, Factsage software was used to calculate the proportion of the liquid phase and the viscosity for MgO-FeO-Fe₂O₃-SiO₂ melts, the melting temperature was measured using slag column deformation, and the microstructure was also observed. The results show that, when the content of Fe₂O₃ is increased from 13.79% to 24.14%, the liquid phase at 1250°C maintains a high proportion of 82.68% and the melting temperature is below 1200°C; The magnetite and hortonolite with high melting points are considerably increased, and the viscosity rises accordingly. The melting and viscous properties for the slag with high content of Fe₂O₃ were improved by adding MgO. Desired slag splashed layer was formed with the saturated Fe₂O₃ and MgO slag.

You might also be interested in these eBooks

Advances in Metallurgical and Mining Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 402)

Pages:

249-252

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.402.249

Citation:

Cite this paper

Online since:

November 2011

Authors:

De Gang Ma, Wei Qing Chen

Keywords:

Lining Life, Magnetite, Nickel Smelting Converter, Slag Property, Slag Splashing

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] C. M. Kenneth, S.U. Yuchu, B. F. Alistair, and L. Zushu: ISIJ International. Vol.45 (2005), p.619

Google Scholar

[2] M. Campforts, E. Jak, and B. Blanpain: Metall. Mater. Trans. B. Vol.40B (2009), p.632.

Google Scholar

[3] X. T. Liu, W. Q. Chen, D. G. Ma, and Z. Q. Hao, C.A. Patent 200810113158.4(2008), In Chinese.

Google Scholar

[4] F. G. Guevara, and G. A. Irons: published on line Metall. Mater. Trans. B. (2011).

Google Scholar

[5] L. N. Zhang, L. Zhang, and M.Y. Wang: Tran. Nonferrous Met. Soc. China. Vol.15 (2005), p.1.

Google Scholar

[6] A. Kondratiew and E. Jak: Metall. Mater. Trans. B. Vol. 32 (2001), p.1015.

Google Scholar

[7] Z. Q. Zhu, J.Q. He: Modem Copper Smelting. Beijing: Science Press, 2003. In Chinese.

Google Scholar
