A 2D Ray Tracing Method Based on the Virtual Source Tree in Urban Environment

Abstract:

In this paper, a new RT method for the calculation of radio coverage in urban environment using a virtual source tree, which is based on the numerical simulation of geometrical optics (GO) and the uniform theory of diffraction (UTD) and can solve some of the problems that other RT methods have, is presented. It is developed for two-dimensional (2-D) environments and can be applied to any complex propagation environment. It is fundamentally a point-to-point tracing method, so reception tests are not required and it guarantees high accuracy. To validate our RT method, signal path loss was calculated, and it was also compared with the published measurements. The results of the proposed method in this paper show good agreement with the measurements.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 1466-1470
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.1466
• Online since: November 2011
• Authors: Zhong Yu Liu, Li Xin Guo, Xiao Yu Ding
• Keywords: Path Loss, Ray-Tracing, Urban Environment, Virtual Source Tree

References

[1] E. G. Papkelis, I. Psarros, I. C. Ouranos, C. G. Moschovitis, K. T. Karakatselos, E. Vagenas, H. T. Anastassiu and P. V. Frangos, A radio coverage prediction model in wireless communication systems based on physical optics and the physical theory of diffraction, IEEE Antennas Propag. Mag., vol. 49, no. 5, pp.156-165, April (2007).

DOI: 10.1109/map.2007.376622

[2] V. Degli-Esposti, F. Fuschini, E. Vitucci, and G. Falciasecca, Speed-up techniques for ray tracing field prediction models, IEEE Trans. Antennas Propagat., vol. 57, no. 5, p.1469–1480, May (2009).

DOI: 10.1109/tap.2009.2016696

[3] S. Seidel, T. Rappaport, Site-specific propagation prediction for wireless in-building personal communications system design, IEEE Trans. Veh. Tech., vol. 43, no. 4, p.879–891, November (1994).

DOI: 10.1109/25.330150

[4] K. Schaubach, N. Davis, Microcellular radio-channel propagation prediction, IEEE Antennas Propag. Mag., vol. 36, no. 4, pp.25-34, August (1994).

DOI: 10.1109/74.317764

[5] Z. Ji, B. -H. Li, H. -X. Wang, H. -Y. Chen, and T. Sarkar, Efficient raytracing methods for propagation prediction for indoor wireless communications, IEEE Antennas Propagat. Mag., vol. 43, no. 2, p.41–49, April (2001).

DOI: 10.1109/74.924603

[6] J. H. Whitteker, Measurements of path loss at 910 MHz for proposed microcell urban mobile systems, IEEE Trans. Veh. Technol., vol. 37, no. 3, pp.125-129, August. (1988).

DOI: 10.1109/25.16538

[7] S. Y. Tan and H. S. Tan, Propagation model microcellular communications applied to path loss measurements in Ottawa city streets, IEEE Trans. Veh. Tech., vol. 44, no. 2, p.313–317, May (1995).

DOI: 10.1109/25.385924
