Simulation and Characterization of a Novel Large Stroke Micromirror

Abstract:

This paper reports on the simulation and characterization of a microelectromechanical system (MEMS) micromirror fabricated with PolyMUMPs. The overall diameter of the hexagonal micrimirror, including mirror plate and 3 supporting cantilevers fixed around, is 450um. A 3D model is built in finite element method (FEM) with COMSOL. Simulations of the elevated height of mirror plate, pull-in voltage and eigenfrequency of the micromirror are carried out. The static and dynamic performances of the fabricated micromirror are characterized by Veeco Optical Profiler and Polytek MEMS System Analyzer. The comparison between measurement and simulation exhibits good concordance. Surface topography measurement shows the elevated height and stress-induced concave deformation of mirror plate almost the same scale as demonstrated in FEM simulation. The Pull-In voltages are measured to be around 32V in current-voltage curve which is almost the same as in FEM simulation with one electrode biased. The fundamental resonant frequency is measured to be 4.3k Hz in torsional motion and 4.9k Hz in piston motion.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 3411-3417
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.3411
• Online since: November 2011
• Authors: Quan Sun, Zong Fu Jiang, Edmond Cretu
• Keywords: Characterization, Finite Element Analysis (FEA), Micro-Electromechanical System (MEMS), Micro-Mirror

References

[1] Hagelin P M, Krishnamoorthy U, Heritage J P and Solgaard O 2000 Scalable optical cross-connect switch using micromachined mirrors IEEE Photon. Technol. Lett. 12 882–4.

DOI: 10.1109/68.853535

[2] Mita M, Miyauchi D, Toshiyoshi H and Fujita H 1998 An out-of-plane polysilicon actuator with a smooth vertical mirror for optical fiber switch application in Proc. IEEE/LEOS Summer Topical Meetings (Monterey, USA 20–24 Jul 1998) II/33–34.

DOI: 10.1109/leosst.1998.689718

[3] Chen W C, Wu C Y and Lee C K 2003 Bi-directional movable latching structure using electrothermal V-beam actuators for optical switch application in Proc. IEEE/LEOS Opt. MEMS (Hawaii, USA 18-21 Aug 2003) pp.149-150.

DOI: 10.1109/omems.2003.1233510

[4] Freeman M O 2003 Miniature high-fidelity displays using a biaxial MEMS scanning mirror Proc. SPIE 4985 56-62.

DOI: 10.1117/12.477816

[5] Yan J, Kowel S T, Cho H J and Ahn C H 2001 Real-time full-color three-dimensional display with a micromirror array Optics Letters 26 1075-1077.

DOI: 10.1364/ol.26.001075

[6] Dudley D, Duncan W and Slaughter J 2003 Emerging Digital Micromirror Device (DMD) Applications Proc. SPIE 4985 14-25.

DOI: 10.1117/12.480761

[7] Michalicek M A, Clark N and Comtois J H 1998 Design and simulation of advanced surface micromachined micromirror devices for telescope adaptive optics applictions Proc. SPIE 3353 805-815.

DOI: 10.1117/12.321697

[8] Waldis S, Zamkotsian F, Clerc P A, Noell W, Zickar M and de Rooij N 2007 Arrays of High Tilt-Angle Micromirrors for Multiobject Spectroscopy IEEE Journal of Selected Topics in Quantum Electronics 13 168-177.

DOI: 10.1109/jstqe.2007.894181

[9] Morzinski K M, Evans J W, Severson S, Macintosh B, Dillon D, Gavel D, Max C, Palmer D, Dillon D, Gavel D, Max C and Palmer D 2006 Characterizing the potential of MEMS deformable mirrors for astronomical adaptive optics Proc. SPIE 6272 627221.

DOI: 10.1117/12.672470

[10] Zhang Y H, Poonja S and Roorda A 2006 Adaptive Optics Scanning Laser Ophthalmoscope using a Microelectro-mechanical (MEMS) Deformable Mirror Proc. SPIE 6138 61380Z.

DOI: 10.1117/12.646934

[11] Dagel D J, Cowan W D, Spahn O B, Grossetete G D, Grine A J, Shaw M J, Rsnick P J and Jokier B 2006 Large-stroke MEMS Deformable Mirrors for Adaptive Optics J. Microelectromech. Syst. 15 572-581.

DOI: 10.1109/jmems.2006.876794

[12] L MC A, Flath M W Kartz, Wilks S C, Young R A, Johnson G W and Ruggiero A J 2002 Free Space Optical Communications Utilizing MEMS Adaptive Optics Correction Proc. SPIE 4821 129-138.

DOI: 10.1117/12.451463

[13] Li J, Chen H Q, Yan G P, Liu Y and Wu P 2005 Improve space laser communication using adaptive optics system based on MEMS technology Proc. SPIE 5985 59851R.

DOI: 10.1117/12.657350

[14] Zhang X M, Chau F S, Quan C, Lam Y L and Liu A Q 2001 A study of the static characteristics of a torsional micromirror Sensors and Actuators A: Physical 90 73-81.

DOI: 10.1016/s0924-4247(01)00453-8

[15] Zhang J L, Zhang Z X, Lee Y C, Bright V M and Neff J 2003 Design and investigation of multi-level digitally positioned micromirror for open-loop controlled applications Sensors and Actuators A: Physical 103 271-283.

DOI: 10.1016/s0924-4247(02)00340-0

[16] Chiou J C, Kou C F and Lin Y J 2007 A micromirror with large static rotation and vertical actuation IEEE Journal of Selected Topics in Quantum Electronics 13 297-303.

DOI: 10.1109/jstqe.2007.892069

[17] Cowan W D, Lee M K, Welsh B W, Jokier B, Bright V M and Roggemann M C 1999 Surface Micromachined Segmented Mirrors for Adaptive Optics IEEE Journal of Selected Topics in Quantum Electronics 5 90-101.

DOI: 10.1109/2944.748110

[18] Carter J, Cowen A, Hardy B, Mahadevan R, Stonefield M and Wilcenski S 2005 PolyMUMPs Design Handbook (Revision 11. 0), MEMSCAP Inc., http: /www. memscap. com/mumps/documents/PolyMUMPs. DR. v11. pdf.

[19] Sun Q, Cai M, Wang N Y, Cretu E 2009 Mechanical design and system-lever analysis of a novel micromirror array Proc. SPIE 7510 751003.

[20] Burns D M and Bright V M 1997 Designs to improve polysilicon micromirror surface topology Proc. SPIE 3008 100-110.

[21] Comtois J, Michalicek A, Cowan W and Butler J 1999 Surface-micromachined polysilicon MOEMS for adaptive optics Sensors and Actuators A 78 54–62.

DOI: 10.1016/s0924-4247(99)00204-6
