Debonding Characterization of SMA/Polymer Morphing Structures

Abstract:

morphing structures are expected to play an increasingly important role in aeronautic applications, among others. Shape memory alloys (SMA) are one of the most promising candidates to date. However, work remains to be done before these structures meet the stringent requirements of their successful integration in an aeronautic context. Research has shown that SMA/Polymer interface strength can be a limiting factor in active deformable structure performance. In this study, the effect on the SMA/Polymer interface strength of various surface treatments, wire geometries and resin types are evaluated. SMA wire geometry is modified through a specific combination of cold rolling and post-deformation annealing, which is capable of maintaining SMA actuating properties while achieving required cross-section area reductions. The most promising thermomechanical processing is finally proposed but results show that further work is required before SMA active elements can safely be used in an active structure.

• Periodical: Advanced Materials Research (Volume 409)
• Pages: 621-626
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.409.621
• Online since: November 2011
• Authors: Charles Fischer, Patrick Terriault, Vladimir Brailovski
• Keywords: Cold-Rolling, Interface, Morphing, Pull-Out, SMA, Structure

References

[1] H.F. Parker: NACA Report, Vol. 77, (1920). p.41.

[2] S. Barbarino, et al.: Journal of Intelligent Material Systems and Structures, Vol. 20, (2009). pp.283-96.

[3] G.S. Bushnell, D. Arbogast, and R. Ruggeri: Shape control of a morphing structure (rotor blade) using a shape memory alloy actuator system (SPIE - The International Society for Optical Engineering 2008).

DOI: 10.1117/12.775927

[4] A.K. Kancharla and D. Roy Mahapatra: Aerodynamic pressure variation over SMA wire integrated morphing aerofoil (American Institute of Aeronautics and Astronautics Inc. 2008).

DOI: 10.2514/6.2008-2044

[5] G. Pritschow, W. Wadehn, and G. Kehl: Shape adaptation of fixed wing aircraft by shape memory alloys (MESSE BREMEN GMBH 2000).

[6] D. Coutu, V. Brailovski, and P. Terriault: Journal of Aircraft, Vol. 46, (2009). pp.730-1.

[7] H.A. Bruck, C.L. Moore, III, and T.M. Valentine: Proceedings of the Society for Experimental Mechanics, Inc, Vol. 51, (2004). pp.62-70.

[8] P. Bettini, et al.: Journal of materials engineering and performance, Vol. 18, (2009). pp.664-671.

[9] H.A. Bruck, C.L. Moore, and T.L. Valentine: Smart Materials and Structures, Vol. 11, (2002). pp.509-18.

[10] K. Jonnalagadda, G.E. Kline, and N.R. Sottos: Exp. Mechanics, Vol. 37, (1997). pp.78-86.

[11] C.L. Moore and H.A. Bruck: Smart Materials and Structures, Vol. 11, (2002). pp.130-139.

[12] P. Chi-kin, L. Kin-tak, and Z. Li-min: Composites Part B, Vol. 36B, (2005). pp.25-31.

[13] T. Georges, et al.: Journal of Mechanical Design, Transactions of the ASME, Vol. 131, (2009). pp.0910061-0910069.

[14] ASTM D2229-10, Standard test method for adhesion between steel tire cords and rubber, (2010).
