Excavation Effect of Tunnel Slope Reinforced with Anti Sliding Pile in Cold Regions Based on 3D-FEM

Abstract:

In order to analyze the effects of tunnel excavation on the stability of tunnel slope reinforced with anti sliding pile and establish 3D elastic-plastic finite element model, the paper focused on the analysis of the deformation of the structural system, the characteristics of the deformation and the rules of the plastic zone of the surrounding rock. The results showed that in the construction process, the maximum vault settlement was about 28mm; the plastic zone occurred mainly in the place surrounding the sliding pile and part of the earth surface, the plastic zone around the vault at the entry of the tunnel was large and tended to connect with the earth surface; the soil arching effect ensured the stability of the slope during the tunnel excavation and construction.

• Periodical: Advanced Materials Research (Volume 413)
• Pages: 170-173
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.413.170
• Online since: December 2011
• Authors: Jin Xing Lai, Hao Bo Fan, Zi Chao Dong
• Keywords: 3D FEM, Anti Sliding Pile, Cold-Regions Tunnel, Excavation Effect

References

[1] J. She,C. He, 3D Elasto-plastic Numerical Simulation of Entire Construction Process for Highway Tunnel[J], Journal of Southwest Jiaotong University, 2005, 20(3): 298-302.

[2] K.J. Shou, A Three-Dimensional Hybrid Boundary Element Method for Non-Linear Analysis of a Weak Plane Near an Underground Excavation[J]. Tunnelling and Und erground Space Technology, 2000, 15(2): 215-226.

DOI: 10.1016/s0886-7798(00)00047-x

[3] WU Bo, GAO Bo, LUO Jian-jun, Numerical Simulation of Reinforcing Effect of Horizontal Drilling Jet-Grouting Pegson Shenzhen Metro Tunnel between Stations, Journal of Southwest Jiaotong University, 2004, 39, 5: 605-608.

[4] JTG D70-2004, Code for design of road tunnel, Beijing: China Communications Press, (2004).

[5] Mao Jianqiang, Zhou Depei, Deformation analysis for landslide-tunnel interaction[J], Journal of Southwest Jiaotong University. 2002, 37, 4: 371-376.

[6] Goodman R.E., Taylor R.L., Brekke T.L., Amodel for the mechanics of jointed rock[J].J. of the Soil Mech. And Foundation Division(SM3), ASME, 1968; 94: 638-659.

DOI: 10.1061/jsfeaq.0001133

[7] Cundall P.A., A Computer model for simulating progressive large-scale movemention blocky rock systems[A] In: Proc. of the IntSymp on Rock Mechanics[C], Nancy, Francy, 1971: 2-8.

[8] Zhang Luxin, Zhou Depei, Cause of creep landslide formation an mechanism of deformation of tunnel[J], Chinese Journal of Rock Mechanics and Engineering, 1999, 18(2): 217-221.

[9] TAO Zhiping, ZHOU Depei, Model Test on Deformation mechanism of Tunnel at Landslide Site[J], Journal of Engineering Geolog, 2003, 11(3): 323-327.

[10] ZHANG Jian-xun, CHEN Fu-quan, JIAN Hong-yu, Numerical analysis of soil arching effects in passive piles[J], Rock and Soil Mechanics, 2004, 25(2): 174-179.
