An On-Line Fatigue Life Monitoring System for Boiler Drums Based on the Inverse Problem of Heat Conduction Method

Abstract:

A method based on solution of the inverse heat conduction problem was presented for online stress monitoring and fatigue life analysis of boiler drums. The mathematical model of the drum temperature distribution is based on the assumptions that the difference of temperature along the longitudinal axis of the boiler drum is negligible with changes only in the radial direction and the circumferential direction, and that the outer surface of drum is thermally insulated. Combining this model with the control-volume method provides temperatures at different points on a cross-section of the drum. With the temperature data, the stresses of the boiler drum are derived according to the FEM and the life expectancy of it is calculated　based on the rain flow method. Applying this method to the cold start-up process of a 300 MW boiler demonstrated the absence of errors caused by the boundary condition assumptions on the inner surface of the drum and an applicable technique for the online stress monitoring and fatigue life analysis of boiler drums.

• Periodical: Advanced Materials Research (Volume 413)
• Pages: 361-366
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.413.361
• Online since: December 2011
• Authors: Peng Wang, Bin Li, Song Ling Wang
• Keywords: Boiler Drum, Finite Element Method (FEM), Rain Flow Method, Temperature Distribution

References

[1] Tsao CH. Thermal stresses in long cylindrical shells. ASME Journal of Applied Mechanics, 1959(3): 147-148.

DOI: 10.1115/1.4011947

[2] Liang YM, Shen YF. Fatigue life estimate of boiler drum based on actual boundary condition stress solution . Journal of Xi'an Jiaotong University, 1999, 33(1): 73-76.

[3] Li B, Chen TK, Shen YF. Study of boiler drum stress on-line detection program based on finite element method . Journal of Xi'an Jiaotong University, 2003, 37(5): 447-450.

[4] Zheng XW, Sun Yu Study of the Methods for Calculating the Low-cycle Fatigue Life of a Supercharged Boiler Drum. Journal of Engineering for Thermal Energy and Power, 2010(3): 184-189.

[5] Yuan Zhen fu, Yuan Zhen fu. The Optimization of Start Up Curves and Real Time Start Up Guide for Power Station Boilers . Power Engineering, 1997(8): 40-45.

[6] Guan DQ, Mo JC, Lu LM. Study on optimization of the starting process of 300MW sets' boilers . Power Engineering, 2005, 25(3): 609-613.

[7] Guan DQ, Mo JC, Lu LM. A study of the optimization of a 1021 t/h boiler start-up process on the basis of the boiler drum service life . Journal of Engineering for Thermal Energy and Power, 2006, 21(1): 31-34, 38.

[8] Necati ÖM, Orlande HRB. Inverse heat transfer: fundamentals and applications. New York: Taylor & Francis, (2000).

[9] Yu Yanzhi; Chen Ruqing; Ma Bin. 3D Thermal Stress and Fatigue Analysis of Drum Wall . Power System Engineering, 1999(06): 13-15.

[10] Russo EP, St Cyr WW, Herrington PD. Thermal stresses in a partially filled horizontal vessel . Journal of Pressure Vessel Technology, 1994, 116(3): 302-305.

DOI: 10.1115/1.2929592

[11] Taler J, Zima W. Solution of inverse heat conduction problems using control volume approach . International Journal of Heat and Mass Transfer, 1999, 42(6): 1123-1140.

DOI: 10.1016/s0017-9310(98)00280-4

[12] Taler J, Weglowski B, Zima W, et al. Analysis of thermal stresses in a boiler drum during start-up . Journal of Pressure Vessel Technology, 1999, 121(2): 84-93.

DOI: 10.1115/1.2883672
