Research on Contact Fatigue of Cylindrical Gear

Abstract:

Based on the dynamic balance principle and contact fatigue properties of cylindrical gear pair, the influence factors of dynamics are researched and the meshing location for the maximum contact stress is accurately determined. Loading spectrum of contact stress is obtained by transient dynamic analysis. At the same time, the corresponding S-N curve for contact fatigue is described in a double logarithmic coordinate system. Then the finite element analysis on the contact fatigue life is carried out by ANSYS Workbench and safety factor for both gears are obtained. It has great significance for evaluating the reliability of the cylindrical gear pair.

• Periodical: Advanced Materials Research (Volumes 415-417)
• Pages: 879-882
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.415-417.879
• Online since: December 2011
• Authors: Xue Yi Li, San Shuai Li, Da Qian Geng, Qing Liang Zeng
• Keywords: Contact Fatigue, Loading Spectrum, Safety Factor, S-N Curve

References

[1] Z.F. Wu: Experimental Study of Contact Fatigue Property for 18Cr2Ni4WA Gears,Acta Armamentarii Vol. 31(2010), pp.598-602, in Chinese.

[2] Z.Z. Li: Influence of Materials and Technology on Gear Contact Fatigue Property, Automobile Technology & Material Vol. 4(2006), pp.12-14, in Chinese.

[3] The Chinese mechanical engineering society material to learn: The Failure Analysis of Gear, China Machine Press, Beijing (1992),in Chinese.

[4] Z.Q. Zeng and X.Z. Zhao: Study about the Effect of Meshing Stiffness and Meshing Damping on Gear Vibration, Machine Tool & Hydraulics Vol. 38(2010), pp.32-34, in Chinese.

[5] W.X. Yao: The Fatigue Life Analysis of Structure, National defence industry press, Beijing (2003), in Chinese.
