Ultrasonic Sector Scanning Method in the Application of the Accurate Determination of the Concrete Bored Pile Defect Position

Abstract:

Based on the detection of cast-in-place concrete defects of bored pile as the research object, the scale of the commonly used method for measuring the determination of the defect position, which can't determine the accurate range is very large defect location of the problem, taking the first measurement method, planing initially determined by fan scanning method to determine the accurate out concrete piles defect position method, and digging pile defect position after the actual situation comparison of verifying test, test results are accurate effect and good. In the concrete bored piles detection, the level measurement method that ultrasonic testing is generally used for measuring the location range of the defects inspects too large range , which brings the inspection people can't determine the accurate defect position , affects the normal construction. Based on the engineering practice of using level measuring method and fan scanning technique combining detection methods to solve the determination on the accurate location of the defects in concrete bored piles.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1128-1132
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1128
• Online since: January 2012
• Authors: De Zhi Liu, Jian Min Ren, Yang Yang
• Keywords: Defect, Detection, Plane Method, Sector Scanning Method, Ultrasonic Wave (UW)

References

[1] CECS, The ultrasonic method to detect defects of concrete technology procedures[M] CECS21: (2000).

[2] Fan Chen, Tianping Xu, The technology of foundation pile quality testing[M] China Architecture & Building Press, (2009).

[3] The technical specifications of building pile foundation [S], China Architecture and Building Press.

[4] Xiping Liang, The research of ultrasonic concrete component internal defects data processing[J] The journal of Jiangxi university of science and technology.

[5] Yansheng Li, Xiaoying Xu, The paper of discussing about concrete perfusion pile body completeness inspection methods [J], Patent 33, 222, 107. (2007).

[6] The People's Republic of the ministry of railways. TB 10218—2008 The technology procedures of railway the foundation pile testing[S]. Beijing: China railway publishing house，(2008).

[7] Hua-You Chai, Kok-Kwang Phoon, Dian-Ji Zhang. Effects of the Source on Wave Propagation in Pile Integrity Testing[J], J. Geotech. Geoenviron. Eng. 136, 1200 (2010).

DOI: 10.1061/(asce)gt.1943-5606.0000272

[8] Xuanming Ding, Hanlong Liu, Jinyuan Liu, Yumin Chen，Wave Propagation in a Pipe Pile for Low-Strain Integrity Testing[J]，J. Eng. Mech. 137, 598 (2011).

DOI: 10.1061/(asce)em.1943-7889.0000263
