Analysis of Tooth Surface Temperature Field and the Influencing Factors of Face Gear Driven

Abstract:

According to the theory of heat transfer, it analyzed the calculating method of tooth friction heating in the process of face gear tooth meshing. It emulational analyzes the thermal coupling of the face gear with ANSYS/LS-DYNA, and extracts the state of each engaged positions in the meshing process, emulate the temperature distribution & temperature changing trends in the process of face gear tooth meshing. Through the temperature measurement experiment the face gear contact, it verifies the correctness of the emulation results. Simultaneously, it also analyzes the influence to the surface temperature of face gear of rotation and load, In the case of other conditions remain unchanged, low-speed is an effective way to prevent instantaneous temperature rise.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1405-1411
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1405
• Online since: January 2012
• Authors: Guo Qi He, Hong Zhi Yan, Wei Hu, Tao Liang Shu
• Keywords: Face Gear Engagement, Friction Heat, Friction Heat Flux, Temperature Field

References

[1] Deng G, KatoM, Maruyama N, et al: Initial temperature evaluation for flash temperature index of gear tooth [J]. Journal of Tribology, Vol. 117(1995), p: 476-480.

DOI: 10.1115/1.2831278

[2] HANDSCHUH R F: Thermal behavior of spiral bevel gears [D]. Cleveland: Case Western Reserve University, (1993).

[3] HANDSCHUH R F, KICHER T P: A method for thermal analysis of spiral bevel gears [J]. Transactions of the ASME, Journal of Mechanical Design, Vol. 118(1996), p: 580-585.

DOI: 10.1115/1.2826932

[4] FANG Zong-de, CHEN Guo-ding, SHEN Yun-wen: Evaluation of Flash Temperature of Helical Gear Teeth [J]. Journal of northwestern polytechnical University, Vol. 2(1992), p: 220-226, in Chinese.

[5] JIN Guang-hu, ZHU Ru-peng, ZHU Zi-bing,: Analysis of Transient Contact Temperature of a Face Gear Drive[J]. Mechanical Science and Technology for Aerospace Engineering, Vol. 28(2009), p: 301-305, in Chinese.

[6] LONG Hui, ZHANG Guang-hui, LUO Wen-jun: Modeling and Analysis of Transient Contact Stress and Temperature of Involutes Gears[J]. Chinese Journal of Mechanical Engineering, Vol. 40(2004), p: 24-29, in Chinese.

DOI: 10.3901/jme.2004.08.024

[7] LONG Hui: Modeling of Surface Temperature in High-Speed Gears and Sensitivity Analysis[D] . Chongqing: Chongqing University, 2004, in Chinese.

[8] XIAO Wang-qing, LI Wei, HAN Jian-you: Thermal Analysis of Involutes Gear Transmission with Unsymmetrical Tooth Profile[J]. Transaction of the Chinese Society for Agricultural Machinery, Vol. 37(2006), p: 164-167, in Chinese.

[9] SUN Shou-qun, ZHU Wei-guang, ZHAO Yu-xiang: Analysis on the influencing factors of the temperature field of involutes gears[J]. Journal of machine design, Vol. 26(2009), p: 59-62. in Chinese.
