Effect of Cold Energy Storage of Single-Well Aquifer Thermal Energy Storage in Sanhejian Coal Mine

Abstract:

Effective implementation of technology of aquifer thermal energy storage (ATES) must form a "ground cold water reservoir" or "ground warm reservoir". In this paper, taking Sanhejian Coal Mine as an example, we analyze the effect of cold energy storage in single-well by analyzing the volume change of cold water body within different temperature ranges. Through the analysis of volume change of cold water body, it can prove that with the same irrigation temperature, the increase of irrigation flow makes the volume and percentage of cold water body in aquifer within different temperature ranges. And the impact on the cold water of 2-5°C is more obvious. With the same irrigation flow, both the cold water body and its percentage of 2-10°C in the condition of 2°C irrigation temperature are more than those in the condition of 5°C. The increase of irrigation flow and the decrease of irrigation temperature are beneficial to cold energy storage, and the effect of cold energy storage of the condition 3 (100m³/h irrigation flow and 2°C irrigation temperature) is the best in these four conditions.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1433-1436
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1433
• Online since: January 2012
• Authors: Yi Zhang, Dong Ming Guo
• Keywords: Aquifer Thermal Energy Storage (ATES), Cold Energy Storage, Cold Water Body, FEFLOW, Simulation

References

[1] He M CH, Zhang Y, Qian Z ZH. Research on doublets wells to store cold energy for heat-harm treatment in deep mine[J]. Coal Geology & Exploration, 2006, 34(5): 23-26. (In Chinese).

[2] He M CH. HEMS deep cooling systems and heat damage control strategy developed [J]. China Basic Science, 2008, (2): 11-16. (In Chinese).

[3] He M CH, Zhang Y, Qian Z ZH. Numerical simulation study on utilizing aquifers to store cool energy in fathing deep mine heat-harm[J]. Journal of hunan university of science & technology (natural science edition), 2006, 21(2): 13-16. (In Chinese).

[4] Zhang Y, Guo D M. Application of aquifer thermal energy storage technology in large temperature difference water source heat pump[J]. MINING　R& D, 2009, 29(2): 56-59. (In Chinese).

[5] Zhang Y, Guo D M, Jiang Y D. Application of Aquifer Thermal Energy Storage Technology in Large Temperature Difference Water Source Heat Pump [J]. MINING R& D, 2009, 29(2): 56-59. (In Chinese).

[6] Cheng X P, Zhou Q L, Guo B H, ect. Application of a microseismic monitoring system in deep mining[J]. Journal of University of Science and Technology Beijing, 2007, 14(1): 6-8. (In Chinese).

[7] Hans J, Diersch G. (translated by Kong X G). Finite Element Subsurface FLOW System. Xuzhou: China University of Ming and Technology Press, 2000. (In Chinese).
