Design of Six Freedom Vibration Acquisition System for Military Vehicle

Abstract:

Design and implementation of six freedom transportation vibration spectrum collection system is presented in this paper. The Attitude and Heading Reference System (AHRS) is used to capture signals including x, y, z, direction linear acceleration, angular rates around Z-axis and pitch, roll degree. The software’s architecture and modules for host computer is designed with object-oriented analysis and design techniques, and the software is implemented with VC++6.0. The test results show that the system was able to collect vehicular vibration information on time and the collection data was replayed on the vibration platform.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1866-1870
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1866
• Online since: January 2012
• Authors: Zhi Xiong Zhu, Shi Shun Zhu, Guo Jun Wang, Yan Zhu
• Keywords: Acquisition System, Six Freedom, Vibration Spectrum

References

[1] Information on http: /www. assistdocs. com/search.

[2] Innalabs AHRS M2, M3 user's manual. INNALABS，2009-02.

[3] GJB 3493-1998. Transport environmental conditions for military materials. Commission of Science Technology and Industry for National Defense (COSTIND), (1998).
