Application System Based on the Combination of Touch Screen and PLC

Abstract:

Combination application of touch screen with PLC has become the mainstream of modern control field, and it achieves control and monitoring to the fieldwork through the touch screen. This paper introduces a control system based on the combination of PLC and touch screen, achieves control to the transducer and fieldwork unit, meanwhile, displays the information collected on the touch screen. The system works reliably with steady performance and is easily to expand, has reached the design requirements.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 2021-2025
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.2021
• Online since: January 2012
• Authors: Hu Zhang, Wen Fu Wu, Zhe Liu, Hai Dong Fu, Yang Wang, Xi Wu Li
• Keywords: Communication, Control, Programmable Logic Controller (PLC), Touch Screen

References

[1] Yanqing Peng: Journal of Lujiang University Vol. 12(2004), pp.82-85, in Chinese.

[2] Qiang Liu, Zhongliang Luo: Journal of Zhengzhou Institute of Light Industry Vol. 20(2005), pp.71-73, in Chinese.

[3] Jie Yu, Xufang Li: MANOFACTURING AUTOMATION Vol. 21(1999), pp.56-58, in Chinese.

[4] Changchu Liao: Programming and application in S7-200 PLC(Mechanical industry press, Beijing 2007), in Chinese.

[5] Pin Lü: Process Automation Instrumentation Vol. 31(2010), pp.45-51, in Chinese.
