Influence of Reinforcement on Temperature and Stress of Hollow Pier

Abstract:

This paper put circular hollow bridge pier under cold wave as an example. Based on solid heat conduction principle, we selected its border and initialized condition according with actual circumstance. Combining solid heat conduction differential equation and generalized hooke’s law which takes temperature stress into account, we have calculated the temperature and stress of concrete piers with different reinforcement ratio by ANSYS finite element software. These results indicate that the longitudinal bars and horizontal ring stirrups in concrete circular hollow pier under cold wave will increase its outer surface temperature tensile stress. Namely the reinforcements in concrete circular hollow pier not only do not prevent its outer surface cracks under the action of cold wave, but will also promote the surface cracks to produce faster. Therein, the contribution of horizontal ring stirrups to the surface cracks is greater than the longitudinal bars.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 1319-1324
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.1319
• Online since: January 2012
• Authors: Yun Fang Wu, Yan Yan Sun
• Keywords: Bridge Pier, Cold Wave, Concrete, Reinforcement, Temperature Field, Thermal Stress

References

[1] China Railway Engineering design and Consulting Group Co., Ltd.(2005) "Code for design on reinforced and pre-stressed concrete structure of railway bridge and culvert." TB 10002.3, China Railway Press, Beijing.In Chinese.

[2] Southeast University, Tianjin University, Tongji University. (2003) "Concrete structure." China Architecture and Industry Press, Beijing. In Chinese.

[3] Runfu Wang, Guorong Chen.(2006)."Temperature Field and Temperature Stress." China Science Press, Beijing. In Chinese.

[4] CARIN L.Roberts-Wollman,John E.Breen,and Jason Cawrse.(2002). "measurements of thermal gradients and their effects on segmental concrete bridge." Journal of Bridge Engineering, ASCE, 7(3), 166-174.

DOI: 10.1061/(asce)1084-0702(2003)8:5(341)

[5] S.Arsoy J.M. Duncan,and R.M. Barker.(2004). "Behavior of a semi-integral bridge abutment under static and temperature-induced cyclic loading." J. Bridge Eng., 9(2), 193-199.

DOI: 10.1061/(asce)1084-0702(2004)9:2(193)

[6] P.J. Barr J.F. Stanon and M.O. Eberhard. (2005). "Effects of temperature variations on precast, prestressed concrete bridge girders." J. Bridge Eng., 10(2), 186-194.

DOI: 10.1061/(asce)1084-0702(2005)10:2(186)

[7] Minxin Guan. Practical calculation method on sunshine temperature field and temperature stress of flexible pier[J]. Bridge Construction,1986,（1）:33-37,69(in Chinese)

[8] Ziming Zhang. (1994). "Thermal stresses of mass concrete subjected to temperature drop. "Journal of Hohai University, 22(6), 94-96. In Chinese.

[9] Xiangqian Kong(1999). "Thermal stress analysis of finite element method." Press of Shanghai Traffic University,China. In Chinese.

[10] China Building Standard Design & Research Institute. (2007). "Building Structure Design Data in Common Use." China Plan Press, Beijing. In Chinese.

[11] Bofang Zhu.(1999). "Thermal Stresses and Temperature Control of Mass Concrete. " China Electric Power Press, Beijing. In Chinese.
