Numerical Simulation of Flow and Heat Transfer Characteristics in Rectangular Channel with Novel Longitudinal Vortex Generators

Abstract:

A novel combined longitudinal vortex generator, comprising a rectangular wing mounted with an accessory rectangular wing, was introduced and the turbulent flow and heat transfer characteristics of a rectangular channel with rectangular winglet pair and combined winglet pair were numerically analyzed. The effects of six parameters were examined. The results show that in the range of the present study, the increase of the six parameters can result in the increase of heat transfer and pressure drop. Specially, the pressure drop decrease at large value of the distance of accessory wing from the channel bottom. The effect of the main attack angle of the combined winglet pair is somewhat different to that of the rectangular winglet pair. The heating plate temperature of the channel with combined winglet pair is lower than that of the channel with rectangular winglet pair, and hence the heat transfer is enhanced.

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 356-362
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.356
• Online since: January 2012
• Authors: Chun Hua Min, Ya Ju Qin, Cheng Ying Qi
• Keywords: Heat Transfer, Longitudinal Vortex Generator, Numerical Simulation, Pressure Drop

References

[1] G. B. Schubauer, and W. G. Spangenberg, Forced mixing in boundary layers, J. Fluid Mech. Vo. 8, p.10–31, (1960).

DOI: 10.1017/s0022112060000372

[2] M. C. Gentry, and A. M. Jacobi, Heat transfer enhancement by delta–wing–generated tip vortices in flat–plate and developing channel flows, ASME J. Heat Transfer vol. 124, p.1158–1168, (2002).

DOI: 10.1115/1.1513578

[3] T. M. Liou, C. C. Chen, and T. W. Tsai, Heat transfer and fluid flow in a square duct with 12 different shaped vortex generators, ASME J. Heat Transfer, vol. 122, p.327–335, (2000).

DOI: 10.1115/1.521487

[4] S. Ferrouillat, P. Tochon, C. Garnier, and H. Peerhossaini, Intensification of heat–transfer and mixing in multifunctional heat exchangers by artificially generated streamwise vorticity, Appl. Therm. Eng. vol. 26, 1820–1829, (2006).

DOI: 10.1016/j.applthermaleng.2006.02.002

[5] K. Torii, K. M. Kwak, and K. Nishino, Heat transfer enhancement accompanying pressure–loss reduction with winglet–type vortex generators for fin–tube heat exchangers, Int. J. Heat Mass Transfer, vol. 45, p.3795–3801, (2002).

DOI: 10.1016/s0017-9310(02)00080-7

[6] L. T. Tian, Y. L. He, Y. G. Lei, and W. Q. Tao, Numerical study of fluid flow and heat transfer in a flat–plate channel with longitudinal vortex generators by applying field synergy principle analysis, Int. Commun. Heat Mass Transfer, vol. 36, p.111–120, (2009).

DOI: 10.1016/j.icheatmasstransfer.2008.10.018

[7] S. M. Pesteei, P. M. V. Subbarao, and R. S. Agarwal, Experimental study of the effect of winglet location on heat rransfer enhancement and pressure drop in fin–tube heat exchangers, Appl. Therm. Eng., vol. 25, p.1684–1696, (2005).

DOI: 10.1016/j.applthermaleng.2004.10.013

[8] R. Vasudevan, V. Eswaran, and G. Biswas, Winglet–type vortex generators for plate fin heat exchangers using triangular fins, Numer. Heat Transfer, vol. 38, p.533–555, (2000).

DOI: 10.1080/104077800750020423

[9] J. X. Zhu, M. Fiebig, and N. K. Mitra, Numerical investigation of turbulent flows and heat transfer in a rib–roughened channel with longitudinal vortex generators, Int. J. Heat Mass transfer, vol. 38, p.495–501, (1995).

DOI: 10.1016/0017-9310(94)00177-w

[10] P. Promvonge, T. Chompookham, S. Kwankaomeng, and C. Thianpong. Enhanced heat transfer in a triangular ribbed channel with longitudinal vortex generators, Energ. Convers. Manage. vol. 51, p.1242–1249, (2010).

DOI: 10.1016/j.enconman.2009.12.035

[11] FLUENT Incorporated, FLUENT 6. 3 User's Guide, Fluent Incorporated Lebanon NH, USA, (2006).
