High Speed Transaction Hardware Channel in Loosely-Coupled Reconfigurable Computing Emulation System

Abstract:

The loosely-coupled reconfigurable computing model includes the host microprocessor in conjunction with an external stand-alone reconfigurable hardware which takes advantage of low cost in technology and development time. It can work as a fast emulation approach to study reconfigurable computing prototype system. One of the key features of such emulation system is the ability to perform the communication. In this paper, we proposed a high speed hardware channel with direct memory access(DMA) transaction method based on Xilinx ML555 development kit and PCI-express(peripheral component interconnection express) endpoint block IP. Experiments show that both read and write transaction speed in this design meet the theoretical maximum speed.

• Periodical: Advanced Materials Research (Volume 462)
• Pages: 456-463
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.462.456
• Online since: February 2012
• Authors: Bo Wei Zhang, Guo Chang Gu, Xing Zhou Zhang, Dong Liu
• Keywords: DMA, Emulation, Hardware Channel, PCI-Express, Reconfigurable Computing

References

[1] Katherine Compton and Scott Hauck, Reconfigurable Computing: A Survey of Systems and Software, ACM Computing Surveys, vol. 34, No. 2, June 2002, p.171–210.

DOI: 10.1145/508352.508353

[2] Christophe Bobda, Introduction to Reconfigurable Computing — Architectures, Algorithm, and Applications, 2007 Springer.

[3] Peng, Integrating PCI-express into PXI and VXI for high perfomance systems, in Proc. of IEEE Autotestcon, Baltimore, MD, USA, Aug. 2007, pp.405-409.

DOI: 10.1109/autest.2007.4374247

[4] H. Frock, M. Geruso, and M. Wetzel, A survey of high speed bus technologies for data movement in ATE systems, in Proc. of IEEE Autotestcon, anaheim, CA, Sep. 2006, pp.655-657.

DOI: 10.1109/autest.2006.283743

[5] L. -G. Zhou, H. -M. Liang, D. -D. Xie, and Z. -K. Wang, Design and implementation of data transfer card based on PCI-express bus, Electronic Measurement Technology, vol. 30, no. 11, pp.28-32, (2007).

[6] Bo Li, Yu Peng, Da-Tong Liu, and Xi-Yuan Peng, A High Speed DMA Transaction Method forPCI-express Devices, Manuscript presented at 2009 IEEE Circuits and Systems International Conference on Testing and Diagnosis, April 28-29, 2009; revised November 4, (2009).

DOI: 10.1109/cas-ictd.2009.4960747

[7] Virtex-5 FPGA ML555 Development Kit for PCI and PCI-express Designs, Xilinx, Inc, UG201 (v1. 4) March 10, (2008).

[8] Virtex-5 FPGA Integrated Endpoint Block for PCI-express Designs, Xilinx, Inc, UG197 (v1. 5) July 22, (2009).

[9] PCI-express Base Specification, 1. 0a ed, PCI SIG, (2003).
