Analysis of the Solenoid Driving Technique for DCT

Abstract:

The control principle of DCT hydraulic system and the working principle of solenoid were described. The solenoid driving circuits based on TLE6220GP and TLE7242-2G of Infineon were designed. The principle of TLE7242-2G control the proportional solenoid and the calculation formula of Kp, Ki were analyzed. The current control waveforms of proportional solenoid in different Kp, Ki were given according to MATLAB simulation.
