Impedance Matching between Signal Generator and Piezoelectric Transducer

Abstract:

In order to acquire enough energy, high power pulse must be used to drive a piezoelectric transducer. At the same time, it is a key technology to design an impedance matching circuit between a signal generator and a piezoelectric transducer so that signal source can transmit energy to the piezoelectric transducer effectively. In the paper, the impedance matching theory is analyzed. And, a method of using an oscilloscope to measure resonance frequency of the piezoelectric transducer is tested, through which, a perfect matching circuit is designed.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 1488-1491
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.1488
• Online since: February 2012
• Authors: Zhen Jiang Tan, Ming Zhou
• Keywords: Impedance Matching, Oscilloscope, Piezoelectric Transducer, Resonance Frequency

References

[1] Jofre, L., Hasley, M. S., Broquetas, A., Reyes, E., Ferrando, and M. Elias-fuste, "Medical Imagingwith Microwave tomographic Scanner," IEEE. Trans. Biomed. Eng., vol.37, no. 3, pp.303-312, 1990.

DOI: 10.1109/10.52331

[2] Bolomey, J., -C., "Recent Eurepean Developments in Active Microwave Imaging for Industrial, Scientific, and Medical Application," IEEE. Trans. Microwave Theory Tech., vol. 37., no. 12, pp.2109-2117, 1989.

DOI: 10.1109/22.44129

[3] Molyneux, J. E. and Witten, A, "Diffraction Tomographic Imaging in a Monostatic easurement Environment," IEEE. Trans. Geosci. Remote Sensing, vol. 31, no. 2, pp.507-511, 1993. 418

DOI: 10.1109/36.214927

[4] AIRMAR TECHNOLOGY CORPORATION. Sensor Design Fundamentals-Piezoelectric Transducer Design for Marine Use. 2000,#17-1025:flf30.WWW.airmar.com.

[5] Bao Shanhui, "Dynamic matching for a piezoelectric transducer," Application Acoustic,vol.17., no 2, pp.16-20, 1998(In Chinese).
