Equilibrium Analysis of Hydrogen Adsorption on Activated Carbon

Abstract:

For developing carbon based adsorbents for hydrogen storage, Staram PCTPro E&E was employed and activated carbon SAC-02 having specific surface area about 2074m2/g was selected to measure isotherms of hydrogen adsorption respectively from temperature range 77.15K-110.15K and 253.15K-293.15K. Isosteres of hydrogen adsorption on the activated carbon was then plotted to determine the isosteric heat of hydrogen adsorption, and temperature dependent of Henry law constants were further applied to set the limit isosteric heat of adsorption at zero surface coverage. Results show that the isosteric heat of adsorption is about 3.6-5.4kJ/mol with a mean value 4.38kJ/mol at zero surface coverage. Results also reveal that adsorption isosteres of adsorption data at different temperature regions bring about a different isosteric heat of adsorption due to the variation in contributions from thermal motion of adsorbate molecules. Conclusions are drawn that adsorption isosteres on the adsorption data in correspondence with the lowest and highest temperatures of the hydrogen storage system should be carried out to determine the isosteric heat of adsorption for effectively managing the thermal effect.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 1652-1658
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.1652
• Online since: February 2012
• Authors: Qing Rong Zheng, Shuai Gao, Chen Jie
• Keywords: Activated Carbon, Adsorption, Heat of Adsorption, Hydrogen Storage

References

[1] Information on http://www1.eere.energy.gov/hydrogenandfuelcells/tech_validation

[2] K. V. Kumar, M.C. M. Castro, M. Martinez-Escandell, M. Molina-Sabio and F. Rodriguez-Reinoso. Heat of adsorption and binding affinity for hydrogen on pitch-based activated carbons. Chemical Engineering Journal Vol. 168(2011), p.972

DOI: 10.1016/j.cej.2010.12.056

[3] R. Paggiaro, P. Bénard and W. Polifke. Cryo-adsorptive hydrogen storage on activated carbon. I: Thermodynamic analysis of adsorption vessels and comparison with liquid and compressed gas hydrogen storage. International Journal of Hydrogen Energy Vol. 35(2010), p.638

DOI: 10.1016/j.ijhydene.2009.10.108

[4] R. Paggiaro, F. Michl, P. Bénard and W. Polifke. Cryo-adsorptive hydrogen storage on activated carbon. II: Investigation of the thermal effects during filling at cryogenic temperatures. International Journal of Hydrogen Energy Vol. 35(2010), p.648

DOI: 10.1016/j.ijhydene.2009.11.013

[5] S. Satyapal, J. Petrovic, C. Read, G. Thomas and G. Ordaz. The U.S. Department of energy's national hydrogen storage project: Progress towards meeting hydrogen-powered vehicle requirements. Catalysis Today Vol. 120(2007), p.246

DOI: 10.1016/j.cattod.2006.09.022

[6] S.Z. Shi and J.Y. Hwang. Research frontier on new materials and concepts for hydrogen storage. International Journal of Hydrogen Energy Vol. 32(2007), p.224

DOI: 10.1016/j.ijhydene.2006.05.015

[7] Gigras, S.K. Bhatia, A.V.A. Kumar and A.L. Myers. Feasibility of tailoring for high isosteric heat to improve effectiveness of hydrogen storage in carbons. Carbon Vol. 45(2007), p.1043

DOI: 10.1016/j.carbon.2006.12.012

[8] L.F. Wang, F.H. Yang, R.T. Yang and M.A. Miller. Effect of surface oxygen groups in carbons on hydrogen storage by spillover. Industrial & Engineering Chemistry Research Vol. 48(2009), p.2920

DOI: 10.1021/ie8014507

[9] L. Zubizarreta, A. Arenillas and J.J. Pis. Carbon materials for H2 storage. International Journal of Hydrogen Energy Vol. 34(2009), p.4575

DOI: 10.1016/j.ijhydene.2008.07.112

[10] Y.X. Yang, L. Bourgeois, C.X. Zhao, D.Y. Zhao, A. Chaffee and P.A. Webley. Ordered micro-porous carbon molecular sieves containing well-dispersed platinum nanoparticles for hydrogen storage. Microporous and Mesoporous Materials Vol. 119(2009), p.39

DOI: 10.1016/j.micromeso.2008.09.044

[11] A.C. Dillon, P.A. Parilla, T. Gennett, K.E.H. Gilbert, J.L. Blackburn, Y.H. Kim, Y. Zhao, S.B. Zhang, J.L. Alleman, K.M. Jones, T. McDonald and M. Heben. Hydrogen storage in carbon-based materials, FY 2004 Progress Report, DOE Hydrogen Program, DOE, United States, 2005, p.245

DOI: 10.1149/ma2006-01/24/879

[12] Q.R. Zheng, A.Z. Gu, X.S. Lu and W.S. Lin. Temperature-dependent state of hydrogen molecules within the nanopore of multi-walled carbon nanotubes. International Journal of Hydrogen Energy Vol. 29(2004), p.481

DOI: 10.1016/s0360-3199(03)00105-8

[13] G.P. Meisner and Q.Y. Hu. High surface area microporous carbon materials for cryogenic hydrogen storage synthesized using new template-based and activation-based approaches. Nanotechnology Vol. 20(2009), p.1

DOI: 10.1088/0957-4484/20/20/204023

[14] R.K. Ahluwalia and J.K. Peng. Automotive hydrogen storage system using cryo-adsorption on activated carbon. International Journal of Hydrogen Energy Vol. 34(2009), p.5476

DOI: 10.1016/j.ijhydene.2009.05.023

[15] J.K. Johnson, J.A. Zollweg and K.E. Gubbins. The Lennard-Jones equation of state revisited. Molecular Physics Vol. 78(1993), p.591

DOI: 10.1080/00268979300100411

[16] B. Smit. Phase diagrams of lennard-jones fluids. Journal of Chemical Physics Vol. 96(1992), p.8639

DOI: 10.1063/1.462271

[17] Q.R. Zheng. A study of hydrogen storage by adsorption on multi-walled carbon nanotube. Thesis for Doctor Degree, School of Mechanical and Power Engineering, Shanghai Jiaotong University, 2002.

[18] D. Nicholson and N.G. Parsonage, in: Computer Simulation and the Statistical Mechanics of Adsorption, Academic Press, London, 1982.

[19] N.B. Vargaftik, in: Handbook of Physical Properties of Liquids and Gases, Pure Substances and Mixtures, 2nd ed., Hemisphere, Washington DC, 1975.

[20] Clark, in: The Theory of Adsorption and Catalysis, Academic Press, New York, 1970.

[21] J.A. Dunne, R. Mariwala, M. Rao, S. Sircar, R.J. Gorte and A.L. Myers. Calorimetric heats of adsorption and adsorption isotherms. 1. O2, N2, CO2, CH4, C2H6, and SF6 on Silicalite. Langmuir Vol. 12(1996), p.5888

DOI: 10.1021/la960495z

[22] A.C. Dillon, K.M. Jones, T.A. Bekkedahl, C.H. Kiang, D.S. Bethune and M.J. Heben. Storage of hydrogen in single-walled carbon nanotubes. Nature Vol. 27(1997), p.377

DOI: 10.1038/386377a0

[23] A.C. Dillon and M.J. Heben. Hydrogen storage using carbon adsorbents: past, present and future. Applied Physics A-Materials Science & Processing Vol. 72(2001), p.133

DOI: 10.1007/s003390100788

[24] M. Heben. Activities in the DOE center of excellence for carbon-based hydrogen storage materials. Advanced Materials & Processes Vol. 163(2005), p.55

[25] G. Constabaris, J.J.R. Sams and J.G.D. Halsey. The interaction of H2, D2, CH4 and CD4 with graphitized carbon black. Journal of Physical Chemistry A Vol. 65(1961), p.367

[26] C.K. Chan, E. Tward and K.I. Boudaie. Adsorption isotherms and heats of adsorption of hydrogen, neon and nitrogen on activated charcoal. Cryogenics Vol. 34(1984), p.451

DOI: 10.1016/0011-2275(84)90001-8

[27] R. Yanik. Calculations of isosteric heats of adsorption of neon and hydrogen adsorbed on charcoal in the temperature range 22-90 K. Vacuum Vol. 47(1996), p.205

DOI: 10.1016/0042-207x(95)00222-7

[28] L. Zhou and Y.P. Zhou. comprehensive model for the adsorption of supercritical hydrogen on activated carbon. Industrial & Engineering Chemistry Research Vol. 35(1996), p.4166

DOI: 10.1021/ie960275g

[29] L. Zhou, Y.P. Zhou and Y. Sun. A comparative study of hydrogen adsorption on superactivated carbon versus carbon nanotubes. International Journal of Hydrogen Energy Vol. 29(2004), p.475

DOI: 10.1016/s0360-3199(03)00092-2
