Simulation of Indoor Environment Monitor Calibration Gas Mantle Based on FLUENT

Abstract:

The concentration error of standard gas in different locations of calibration system will have different degrees of impact on accuracy of calibration results. Among them, concentration of standard gas in gas mantle that combine detection sensors and gas transmission pipelines show the greatest impact on calibration results. In order to realize monitoring and analysis of the overall calibration process, this paper simulated gas concentration change status during calibration process of indoor environmental monitor gas mantle by FLUENT software. Gas concentration change status and sensor measurement accuracy at situations of different size sensors placed in the same gas mantle at the same location and same sensor placed in the same gas mantle at different location were analysed. Simulation results show that to make gas most quickly and evenly filled gas mantle, gas mantle size should be slightly larger than sensor and sensor should be placed in the top of the mantle as far as possible. On this condition, it can ensure gas concentrations error range between sensor workface and the inlet are within ±2%, thereby ensuring the accuracy of calibration results.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 2217-2222
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.2217
• Online since: February 2012
• Authors: Sui Jun Yang, Jia Ying Song, De Xin Hou, Shu Liang Ye
• Keywords: Calibration, Gas Mantle, Indoor environment monitor, Simulation

References

[1] W.K. Liu: Tsinghua University (2004), p.23.

[2] X. Liu, X.F. Ge: Energy Research and Utilization. Vol. 02(2003), p.36.

[3] Q.F. Deng, Y.Z. Dong, A.L. Shen: Digital Manufacturing and Automation (2010), p.740.

[4] B.J. Zhong, H. Wu: Journal of Engineering Thermophysics. Vol. 26(2005), p.51.

[5] W.P. Zhang, Z.P. Feng: Power Engineering. Vol. 24(2004), p.37.

[6] T. Amagai, T. Ohura: ICROS – SICE (2009), p.4484.

[7] Z. Yao, K.M. Chen: Journal of University of Shanghai for Sci. and Tech.. Vol. 24(2002), p.137.

[8] Y.L. Xu, Y.C. Xu, X. Liang: Water Conservancy & Elec. Power Mach.. Vol. 27(2005), p.39.

[9] Y.X. Ren, H.X. Chen. Tsinghua University Press (2006), p.186.
