An Assessment of Cutting Force for Dental Implant Drilling

Abstract:

Bone drilling is widely used in orthopedics and dental surgery; it is a technically surgical procedure. Recent technological improvements in this area are focused on efforts to reduce forces in bone drilling. The aim of this study was to compare changes in cutting force during dental bone drilling at various drilling conditions and drill tool geometry. In the present in vitro study, dog jaw bone with uniform thickness of cortical bone was used. Cutting force changes were measured during drilling process. Drill jig was designed and manufactured to fix jaw workpiece and mounted on the tool dynamometer to measure cutting force in drilling process. The dental implant drilling tests were conducted at various cutting speeds and feed rates. In this study drilling thrust force was observed 1.5~3.6[N] for MS type implant drilling and 3.1~4.9[N] for conventional high speed steel drilling, respectively. This further research will provide a basic quantitative approach for the timely issue of wide application of implant drilling in dental and orthopedic surgery fields.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 2542-2547
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.2542
• Online since: February 2012
• Authors: Joon Hwang, Eui Sik Chung, Yong Kyu Lee
• Keywords: Cutting Force, Dental Implant Drilling, Finite Element Analysis (FEA), Tool Dynamometer

References

[1] Adell R Lekholm U, Rockler B, Branemark PI: A 15 year study of osseointegrated implants in the treatment of the edentulous jaws, International J. of Oral Surgery, Vol. 6, pp.387-416 (1981)

DOI: 10.1016/s0300-9785(81)80077-4

[2] J.S. Strenkowski, C.C Hsieh, A.J. Shih, An analytical finite element technique for predicting thrust force and torque in drilling, International J. of Machine Tools & Manufacture 44, pp.1413-1421 (2004)

DOI: 10.1016/j.ijmachtools.2004.01.005

[3] Y.H Yun, D.H Jeon, J. Hwang, Analysis of cutting force for implant drilling, Proceeding of Korean Society of Precision Engineering Autumn Conference (2009)

[4] F. Karaca, B. Aksakal, M. Kom, Influence of orthopedic drilling parameters on temperature and histopathology of bovine tibia: An in vitro study, Medical Engineering & Physics, pp.1221-1227 (2011)

DOI: 10.1016/j.medengphy.2011.05.013

[5] S.W. Wu, C.C. Lee, P.Y. Fu, S.C. Lin, The effects of flute shape and thread profile on the insertion torque and primary stability of dental implants, Medical Engineering & Physics, article in press (2011)

DOI: 10.1016/j.medengphy.2011.09.021

[6] C.E. Misch, Contemporary Implant Dentistry, 2th Ed, Missouri, Mosby (1999)

[7] Ikeue Dazuohga, Hurui Danino, Present of Soft Tissue Management for Immediate Implant Placement, Quintessence, Vol.9, No.10, 155-163 (2005)

[8] Ken Akimoto, Tomas Junge, The Art and Science of Immediate Implants, Quintessence, Vol.11, No.5, 15-31 (2006)

[9] P. Paszenda, M. Basiaga, FEM Analysis of Drills Used in Bone Surgery, Archives of Materials Science and Engineering, Vol.36, Issue 2, 103-109 (2009)

[10] OSSTEM Implant System, OSSTEM, (2008)
