A Geometric Error Identification and Simulation Method Based on Laser Tracker for Large-Scale Multi-Axis NC Machine Tools

Abstract:

To evaluate the profile error of manufacture mainly caused by geometric error of machine tool, this paper proposes a geometric error identification and profile error simulation method. The identify method measures each axis of machine tool based on laser tracker, then using the least square method to fit the axis, as a result the coordinate system of each axis can be built. The geometric error of machine tool can be gained by analysis of the coordinate system. Building the kinematics model of large-scale multi-axis NC machine tool considered the geometric error, then using MATLAB and UG second development to achieve simulation of profile error.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 556-560
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.556
• Online since: February 2012
• Authors: Ji Yang Ma, Fang Yu Peng, Rong Yan, Jing Wu
• Keywords: Geometric Error Identification, Laser Tracker, Multi-Axis Machine Tool

References

[1] Tao Ye, Cai-Hua Xiong. Geometric parameter optimization in multi-axis machining[J], Computer-Aided Design. Vol. 40 (2008), pp.879-890

DOI: 10.1016/j.cad.2008.05.005

[2] C.Eppler, T.Garber. Influence of the Dynamic Stiffness on the Accuracy of PKM[J], Parallel Kinematics Seminar, April 2002, p.1~12

[3] Guiquan Chen, Jingxia Yuan, Jun Ni. A displacement measurement approach for machine geometric error assessment[J], International Journal of Machine Tools & Manufacture, Vol. 41 (2001), p.149–161

DOI: 10.1016/s0890-6955(00)00049-3

[4] A.C. Okafor, Derivation of machine tool error models and error compensation procedure for three axis vertical machining center[J], International Journal of Machine Tools & Manufacture, Vol. 40 (2000), pp.199-213

DOI: 10.1016/s0890-6955(99)00105-4

[5] Erik L.J. Bohez, Bancha Ariyajunya, Chanin Sinlapeecheewa, Tin Maung Maung Shein, Do Tien Lap, Gustavo Belforte. Systematic geometric rigid body error identification of 5-axis milling machines[J]. Computer-Aided Design, Vol. 39 (2007), p.229–244

DOI: 10.1016/j.cad.2006.11.006

[6] HE Yao-xiong, ZHOU Yun-fei, ZHOU Ji. A Generalized Post-processing Algorithm to Compensate Geometric Errors of Multi-axis NC Machine Tools with Arbitrary Configuration[J]. Journal of Applied Sciences, Vol. 20 (2002), pp.85-89.(chinese)

[7] V. S. Kiridena, Kinematics modeling of quasistatic errors of three-axis machining center[J]. International Journal of Machine Tools & Manufacture, Vol. 34(1994), pp.85-100

DOI: 10.1016/0890-6955(94)90042-6
