Effects of Geometric Misalignment Caused by Girth Weld on Fatigue Behavior of a Cylindrical Pressure Vessel

Abstract:

The paper presents the results of finite element analysis of a pressurized vessel typically made of steel 1025 and containing the weld misalignment at the cylinder-to-cylinder junction. This misalignment considered in the vessel’s structure is because of girth weld that is found in most of the fabrications of such type of structures. Geometric misalignment of 50% of thickness is considered for this particular study. The work evaluates the geometrical effects of misalignment on the fatigue behavior of the pressure vessel to quantify its consequences in term of fatigue life and maximum damage. Finite Element (FE) analysis is performed by the use of ANSYS on one quarter of the structure due to symmetry. A significant effect of misalignment on fatigue life of the cylinder has been found and is presented with maximum anticipated damage in the critical areas.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 1066-1069
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.1066
• Online since: February 2012
• Authors: Musharaf Abbas, Rehan Qayyume, Jamal Hussain Afridi
• Keywords: Fatigue Life, Finite Element Analysis (FEA), Misalignment, Pressure Vessel Steel

References

[1] H. H. Bednar: Pressure vessel design handbook, 2nd Ed. Van Nostrand Reinhold, 1986.

[2] Y.H. Zhang, S.J. Maddox: Investigation of fatigue damage to welded joints under variable amplitude loading spectra, International Journal of Fatigue 31 (2009) 138–152.

DOI: 10.1016/j.ijfatigue.2008.04.006

[3] C.M. Sonsino: Effect of residual stresses on the fatigue behaviour of welded joints depending on loading conditions and weld geometry, Int. J Fatigue 31 (2009) 88–101.

DOI: 10.1016/j.ijfatigue.2008.02.015

[4] T.L. Teng, C.P. Fung, P.H. Chang: Effect of weld geometry and residual stresses on fatigue in butt-welded joints, Int. Journal of Pressure Vessels and Piping 79 (2002) 467–482.

DOI: 10.1016/s0308-0161(02)00060-1

[5] S.M. Beden, S. Abdullah, A. K. Ariffin: Fatigue Life Assessment of Different Steel-Based Shell MaterialsUnder Variable Amplitude Loading,European Journal of Scientific Research, ISSN 1450-216X Vol.29 No.1 (2009), pp.157-169.

[6] J.Rudolph, C. Schmitt, E. Weib: Fatigue lifetime assessment procedures for welded pressure vessel components, Int. Journal of Pressure Vessels and Piping 79 (2002) 103-112.

DOI: 10.1016/s0308-0161(01)00139-9

[7] I.Lotsberg: Stress concentration factors at welds in pipelines and tanks subjected to internal pressure and axial force, Marine Structures 21 (2008) 138–159.

DOI: 10.1016/j.marstruc.2007.12.002

[8] T. B. Peter: Elastic Stresses at a Mismatched Circumferential Joint in a Pressurized Cylinder Including Thickness Changes and Meridional Load, Lewis Research Center, Cleveland, OHIO, USA, NASA (1966).

[9] W.C. Morgan and P.T. Bizon: Comparison of Experimental and Theoretical Stresses at a Mismatch in a Circumferential Joint in a Cylindrical Pressure Vessel (1966), NASA TN D-3608.

[10] T. Aseer Brabin: Finite Element Analysis of Cylindrical Pressure Vessels having a Misalignment in a Circumferential Joint, Int. Journal of Pressure Vessels and Piping (2010).

DOI: 10.1016/j.ijpvp.2010.02.004

[11] American Society for Materials: Fatigue and Fracture, ASM Metals Handbook Vol.19, 1998.
