Modeling and Simulation of Large Erecting System Based on Virtual Prototyping

Abstract:

The virtual prototyping model of large erecting system is established by means of ADAMS and AMESim software. Based on the theory of multi-rigid body dynamic, the topology description of erecting system is given. Dynamics analysis model of large erecting system is built in ADAMS software, and mechanics character is given through the analysis of the erecting system. The simulation model of hydraulic system is built using AMESim software. Collaborative simulation based on the interfaces of ADAMS and AMESim is discussed, and the dynamic characteristic of the erecting system is simulated based on the interfaces of ADAMS and AMESim. Some simulation results are given to demonstrate the validity of the proposed model. This method provides a new approach for the modeling and simulation of electro-mechanical systems.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 2462-2465
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.2462
• Online since: February 2012
• Authors: Yong Bao Feng, Chang Lin Ma, Xiao Song Guo, Chuan Qiang Yu
• Keywords: Adam, AMEsim, Modeling, Simulation, Virtual Prototyping

References

[1] Huang Xian-xiang, GAO Qin-he, GUO Xiao-song, Dynamic Modeling of Erected Process for Large Mechanism, Journal of system simulation, March 2002.

[2] Salah Faik, Holly Witteman: Modeling of Impact Dynamics: A Literature Survey, International ADAMS User Conference, 2000.

[3] Zhang Wei, Lu Bao-chun, Wu Hui-zhong. Modeling and Simulation Approach for Multi-disciplinary Virtual Prototyping. In: Proceeding of the 4th World Congress on Intelligent Control and Automation: Shanghai, P.R. China, 2002, 1586~1590.

DOI: 10.1109/wcica.2002.1020854

[4] Information on http://www.mscsoftware.com/adams/.

[5] Information on http://www.amesim.com/.
