Deploying Analyses of Large Deployable Space Antenna under Gravity Environment

Abstract:

The gravity is a serious problem for the deploying experiments of a large deployable space antenna on the ground. With the increasing trend for much bigger size deployable structures, new ground experiment methods with expected effects or with low cost should be explored. On this special object, we propose several deploying schemes from theoretical design, to practical design and then to actual design on a new folded hoop-rib mesh antenna structure we proposed before. Through the fundamental processes from theoretical analyses to actual experiments, it shows that the fairly complex mechanism can be deployed successfully, which reveals that the new deploying antenna structure design is feasible and reasonable.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 2493-2498
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.2493
• Online since: February 2012
• Authors: Fei Zheng, Mei Chen, Hai Ming Hao, Jiu Li Zhang
• Keywords: Deploying Analysis, Gravity Environment, Hung System, Large Deployable Antenna

References

[1] S. Lienard, J.D. Johnston, B. Ross and J. Smith, Dynamic Testing of a Subscale Sunshield for the next Generation Space Telescope (NGST), 42nd AIAA Structures, Structural Dynamics, and Materials Conference, Seattle, WA, April 16-19 (2001)

DOI: 10.2514/6.2001-1268

[2] D.M. Murphy, B.D. Macy and J.L. Gaspar, Demonstration of a 10-m Solar Sail System, Information on ABLE Engineering Co. Inc (2004)

[3] M. Leipold, H. Runge and C. Sickinger, Large Sar Membrane Antennas with Lightweight Deployable Booms, 28th ESA Antenna Workshop on Space Antenna Systems and Technologies, ESA/ESTEC, May 31 - June 03 (2005)

[4] A. Meguro, K. Shintate, M. Usui and A. Tsujihata, Acta Astronautica Vol.65 (2009), p.1306–1316

DOI: 10.1016/j.actaastro.2009.03.052

[5] M.D. Stegman, M. Fedyk and S. Kuehn, Solar Thermal Vacuum Testing of Deployable Mesh Reflector for Model Correlation, z03_0204, IEEE Aerospace Conference Proceedings, March 6 - 13, (2010)

DOI: 10.1109/aero.2010.5446961

[6] G.W. Marks, M.T. Reilly and R.L. Huff, The Lightweight Deployable Antenna for the MARSIS Experiment on the Mars Express Spacecraft, Proceedings of the 36th Aerospace Mechanisms Symposium, Glenn Research Center, May 14-17 (2002)

[7] A.W. Mast, Electronic Antenna Calibration System and Measurements for Compensating Real-Time Dynamic Distortions, z03_0205, IEEE Aerospace Conference Proceedings, March 6 - 13, (2010)

DOI: 10.1109/aero.2010.5446958

[8] F. Zheng, M. Chen, W. Li and P. Yang, Conceptual Design of a New Huge Deployable Antenna Structure for Space Application, z03_0401, IEEE Aerospace Conference Proceedings, March 1 - 8, (2008)

DOI: 10.1109/aero.2008.4526312
