Kinematic Characteristics and Optimization Analysis of Elliptical Geared Hoeken Mechanism

Abstract:

Kinematic characteristics of Hoeken mechanism is analyzed. Variable ratio transmission characteristics of elliptical gear is obtained. Elliptical geared Hoeken mechanism is presented. Kinematic characteristics of elliptical geared Hoeken mechanism is clarified. Eccentricity is optimized. The elliptical geared Hoeken mechanism with approximate uniform rectilinear motion is designed. The methods in this paper facilitate the innovation design of the mechanism with approximate uniform rectilinear motion.

• Periodical: Advanced Materials Research (Volumes 482-484)
• Pages: 1869-1873
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.482-484.1869
• Online since: February 2012
• Authors: Zhi Dong Huang, Yun Pu Du, Zhao Gang Zhang
• Keywords: Elliptical Gear, Hoeken Mechanism, Kinematic Characteristics, Uniform Rectilinear Motion

References

[1] T.X. Liu, D.C. Miao and Y.F. Zhang: Journal of Heilongjiang August First Land Reclamation University Vol. 16 (2004), pp.22-26 (In Chinese)

[2] X.T. Wu and G.H. Wang: Noncircular gear and non-uniform ratio motion (China Machine Press, China 1997).

[3] X.Q. Gao, S.Q. Yang and L. Ma: Journal of Taiyuan University of Technology Vol. 33 (2002), pp.41-43 (In Chinese)

[4] C.Z. Guo, W. Fu and Z.Q. Peng: Mechanical Science and Technology for Aerospace Engineering Vol. 21 (2001), pp.771-773 (In Chinese)

[5] J.L. He, X.T. Wu and J.G. Li: Chinese Journal of Mechanical Engineering Vol. 40 (2004), pp.62-65 (In Chinese)

[6] F.S. Li: Transmission design of noncircular gear and special gear (China Machine Press, China 1983).
