Inertial Piezoelectric Micro Rotary Actuator

Abstract:

A newly inertial piezoelectric rotary actuator is proposed based on controlling the orderly changes of friction force between the rotator and supporting faces in mechanical way. The dynamic simulation model of the actuator is derived. A prototype small inertial rotary actuator characterized by two symmetric piezoelectric stacks has been fabricated based on the proposed method. The actuator can rotate when it is powered with a square-wave or sine-wave voltage. The experimental and simulation results show that its angular speed is proportional to both the driving voltage’s amplitude and the frequency. The experimental results also show good agreement with the simulation analysis.

• Periodical: Advanced Materials Research (Volume 487)
• Pages: 208-211
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.487.208
• Online since: March 2012
• Authors: Jian Ming Wen, Ji Jie Ma, Zhong Hua Zhang, Guang Ming Cheng, Jun Wu Kan
• Keywords: Friction, Inertial Drive, Piezoelectricity, Rotary

References

[1] Y-T Liu, C-K Wang . A study of the characteristics of a one-degree-of-freedom positioning device using spring-mounted piezoelectric actuators . Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science, vol. 223, pp.2017-2027, (2009).

DOI: 10.1243/09544062jmes1422

[2] Dong-Soo Paik, Kyoung-Ho Yoo, Chong-Yun Kang. Multilayer piezoelectric linear ultrasonic motor for camera module. J Electroceram. vol. 22, pp.346-351, (2009).

DOI: 10.1007/s10832-008-9513-3

[3] Scottl. Sharp, Jefferys. N. Paine，Jonathan D. Blotter. Design of a Linear Ultrasonic Piezoelectric Motor. Journal of Intelligent Material Systems and Structures, vol. 21, pp.961-973, (2010).

DOI: 10.1177/1045389x10374890

[4] Wei Gao, Shinji Sato, Yoshikazu Arai. A linear-rotary stage for precision positioning. Precision Engineering, vol. 34, pp.301-306. (2010).

DOI: 10.1016/j.precisioneng.2009.07.003

[5] Chih-Jer Lin, Sheng-Ren Yang. Precise positioning of piezo-actuated stages using hysteresis observer based control[J]. Mechatronics, vol. 16, pp.417-426(2006).

DOI: 10.1016/j.mechatronics.2006.03.005

[6] Yung-Tien Liu, Rong-Fong Fung, et al. Precision position control using combined piezo-VCM actuators[J]. Precision Engineering, vol. 29, pp.411-422(2005).

DOI: 10.1016/j.precisioneng.2004.12.009

[7] Yung-Tien Liu, Guo-You Le. A 3-DOF Rotational Precision Positioning Stage using Spring-mounted PZT Actuators[J]. Towards Synthesis of Micro-/Nano-systems, vol. 20, pp.121-126(2007).

DOI: 10.1007/1-84628-559-3_20

[8] Chih-Liang Chu, Sheng-Hao Fan, et al. A novel long-travel piezoelectric-driven linear nanopositioning stage [J]. Precision Engineering, vol. 30, pp.85-95(2006).

DOI: 10.1016/j.precisioneng.2005.05.002

[9] Yoshihiro Nomura, Hisayuki Aoyama. Development of inertia driven micro robot with nano tilting stage for SEM operation[J]. Microsyst Technol , vol. 13, pp.1347-1352(2007).

DOI: 10.1007/s00542-006-0360-3

[10] Kee-Joe Lima, Jong-Sub Lee, et al. Fabrication and characteristics of impact type ultrasonic motor[J]. Journal of the European Ceramic Society, vol. 27, pp.4159-4162(2007).
