Analysis of Laminate Configuration on Impact Properties of Glass Fibre Epoxy Nanocomposites

Abstract:

The impact behaviors of glass fibre reinforced/epoxy nanocomposites were studied by experimental using instrumental falling weight testing machine at three different energy levels. Two types of laminates were prepared by hand lay-up method with varying nanoclay into the epoxy in a 1%, 3% and 5%, respectively. The structures of nanocomposites were studied using X-ray diffraction (XRD). It was found that the nanoclay was orderly exfoliated in the epoxy resin. The impact properties of maximum load and energy absorption were determined. It was observed that addition of 3% nanoclay into the epoxy, the maximum load was enhanced by 32% and energy absorption by 24% at the energy level of 24.89J. The impact fractured surface morphology of the glass fibre/epoxy nanocomposites was analyzed using scanning electron microscopy (SEM).

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 488-489)

Pages:

686-690

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.488-489.686

Citation:

Cite this paper

Online since:

March 2012

Authors:

A. Thiagarajan, K. Palaniradja, N. Rajesh Mathivanan, M. Naresh

Keywords:

Energy Absorption, Glass Fiber, Nanocomposite, Scanning Electron Microscope (SEM), X-Ray Diffraction (XRD)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] S. Ganapathy, K.P. Rao: Comput. Struct Vol. 68(1998), p.627.

Google Scholar

[2] R. Velmurugan, G. Balaganesan: Lat. Am. J. Solids. Struct Vol. 8(2011), p.9.

Google Scholar

[3] F . Avila, M.I. Soares, Almir Silva Neto: Int. J. Impact. Eng Vol. 34 (2007), p.28.

Google Scholar

[4] M. Mariatti, P. K. Chum: J. Reinf. Plast. Compos Vol. 24 (2005), p.1713.

Google Scholar

[5] J.N. Baucom M.A. Zikry: Composites: Part A Vol. 36(2005), p.658.

Google Scholar

[6] Z.Y. Zhang, M.O.W. Richardson: Compos. Struct Vol. 81 (2007), p.195.

Google Scholar

[7] Bernd Wetzel, Frank Haupert, Ming Qiu Zhang: Compos. Sci. Technol Vol. 63(2003), p. (2055).

Google Scholar

[8] S.K. Srivastava, I.P. Singh: J. Nano. Res Vol. 15 (2011), p.41.

Google Scholar

[9] ASTM D 3029. Standard test method for impact resistance of rigid plastic sheeting or parts by means of a tup (Falling Weight). Philadelphia: American Society for Testing and Materials; (1982).

DOI: 10.1520/d3029

Google Scholar

[10] R. Maharsia, H. Nikhil Gupta, J. Dwayne: Mater. Sci. Eng A Vol. 417(2006), p.249.

Google Scholar
