The Linear Auto Disturbances Rejection Controller Application in Beam Magnetic Suspension System of Gantry Moving Type Numerical Control Machine Tool

Abstract:

When gantry-moving type numerical control machine works, support beams of the maglev system will exist outside disturbance, internal system parameter variations and unmodeled dynamics and so on, these factors will reduce system processing accuracy. We presented that suspension air-gap of beam suspension system was controlled by using the auto disturbance rejection control technology. The auto disturbances rejection controller can regard system model parameter variations and external disturbance influence of system as comprehensive disturbance, automatic on-line estimation and compensation. Meanwhile, for solving the traditional auto disturbances rejection controller’s problems which are much more parameters and complex parameters adjustment, the linear auto disturbances rejection controller was used. Under the precondition of ensuring control effect, parameters adjustment process of the auto disturbances rejection controller was greatly simplified. The simulation results show that beam magnetic suspension system using the linear auto disturbance rejection control scheme can achieve control requirements and achieve beams friction-free stable suspension.

• Periodical: Advanced Materials Research (Volume 499)
• Pages: 423-427
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.499.423
• Online since: April 2012
• Authors: Chun Fang Liu, Xiu Meng Ren, Li Mei Wang
• Keywords: Double Loop Control, Gantry-Moving Type Numerical Control Machine Tool, Single Electromagnetic Levitation System, Suspension Air-Gap, The Linear Auto Disturbances Rejection Controller

References

[1] Han Jingqing. Auto Disturbances Rejection Control Technique [J]. Frontier Science, 2007(1):24-31.

[2] Wang Limei, An Mingwei, Liu Chunfang. Sliding Mode Control of Magnetic Levitation Used in Gantry Machine Tool [J]. MANUFACTURING TECHNOLOGY & MACHINE TOOL, 2010(2):54-57.

DOI: 10.1109/cmce.2010.5610000

[3] Han Jingqing. Nonlinear State Error Feedback Control Law-NLSEF [J]. CONTROL AND DECISION, 1995, 10(3):221-225.

[4] Han Jingqing. The Extended State Observer Of a Class of Uncertain Systems [J]. CONTROL AND DECISION, 1995,10(1):85-88.

[5] Sun Liang, Wu Genzhong. Application and Optimize Design of Active Disturbance Rejection Controller [J]. Electric Machines & Control Application, 2010, 37(3):26-30.

[6] Wang Limei, Shi Jia. Research on crossbeam magnetic levitation control system of gantry moving numerical control machine tool [J]. Manufacturing technology & machine tool, 2008, (2): 79-82.

[7] Wang Bingshu, Jiang Ping, Lin Yongjun, Hao Jingyu. Building User-defined Block Library for Active Disturbance Rejection Control Technology in SIMULINK [J]. Journal of System Simulation, 2010, 22(3):610-615.
