The Analysis and Evaluation Method of Assembly Accuracy Reliability of Heavy Duty Machine Tool

Abstract:

Geometry constraint and physical constraint change because the structure is complex, tonnage is large, and assembly load is complex on heavy duty machine tool, assembly relation is changed for repeated assembly, then, the assembly accuracy reproducibility and assembly accuracy retentivity decline, which results in the decrease of assembly reliability. According to this problem, the interaction of geometry constraint and physical constraint is discussed in this paper, the influence factors of assembly accuracy reproducibility and assembly accuracy retentivity are respectively analyzed, the establishing, demolition and re-establishing of assembly relation effects assembly accuracy reproducibility, and evolution of assembly relation with time effects assembly accuracy retentivity, which are respectively revealed. Using margin method to evaluate assembly accuracy reliability, the criterion and evaluation method of assembly accuracy reliability is proposed, in order to provide reliable and quantitative criterion for assembly process design, and reasonably set safety margin of geometry constraint and physical constraint, form reliable assembly process, realize that the assembly accuracy is controlled and improved by assembly.

• Periodical: Advanced Materials Research (Volume 500)
• Pages: 608-613
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.500.608
• Online since: April 2012
• Authors: Feng Lan Cheng, Bin Jiang, Ying Li, Min Li Zheng
• Keywords: Assembly Accuracy Reliability, Assembly Relation, Evaluation Method, Heavy Duty Machine Tool

References

[1] Y.M. Zhang and X.Z. Huang: Journal of Mechanical Engineering. Vol. 45(2009), pp.105-109.

[2] Y. Zhang and M.S. Yang: Journal of Mechanical Engineering. Vol. 43(2007), pp.1-6.

[3] N.K.S. Lee and H.Y. Grace: Journal of Manufacturing Science and Engineering. Vol. (2003), pp.595-599.

[4] M.V. Raj and S.S. Sankar: International Journal Advanced Manufacturing Technology. Vol. 57(2011), pp.795-810.

[5] C.W. Tan and T.G. Lim: IEEE Transactions on advanced packaging. Vol. 32(2009), pp.650-655.

[6] P.Z. Li, W.M. Zhang and Y. Lei: International Conference on Measuring Technology and Mechatronics Automation. Vol. 105(2009), pp.754-756.

[7] N. K.S. Lee, Y.F. An and F. Tsung: International Journal Advanced Manufacturing Technology. Vol. 25(2005), p.493–499.

[8] C.C. Li: Machine Tool and Hydraulics. Vol. 37(2009), pp.27-30.
