A Virtual Crankshaft Dynamic Balance Measuring System Based on VB

Abstract:

A crankshaft dynamic balance system designed based on VB is proposed in this thesis. The imbalance can be measured by using computing software and signal processing technology. The development principle, method, hardware and software system are all introduced. The modular design is used in software system. The touch-screen device is used to realize the data display, storage and analysis. And the imbalance mass and position can be displayed on the virtual instrument interface. Real-time monitoring and accurate information can be completed by the system. The experiment result shows this system is easy in operating, high in capability/price ratio and high in balancing precision. It can meet the producing demands and has good market prospects.

• Periodical: Advanced Materials Research (Volume 500)
• Pages: 709-714
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.500.709
• Online since: April 2012
• Authors: Xin Wei Wang, Li Mu
• Keywords: Crankshaft, Dynamic Balance, Influence Coefficient Method, Visual Basic

References

[1] JIANG Zhanping, TANG Yike. Machine Tool & Hydraulics. 38(2001) , p.75.

[2] Liu, Z.S. Key Engineering Materials. 04 (2004), p.751.

[3] IA Shoufeng1, ZHANG Xia, ZHANG Xinguang. Modern Manufacturing Technology and Equipment. 3(2009) , p.16.

[4] MAI Fanjin, Visual Basic Program Design(National Defence Industry Press, Beijing 2008).

[5] SHEN Hong, VB Program Design(Tsinghua University Press , Beijing 2010).
