Working Principle and Performance of Wire Electrical Discharge Machining

Abstract:

Wire electrical discharge machining (WEDM) is an advanced thermal machining process capable of accurately machining parts with complicated shapes, especially for the parts that are very difficult to be machined by traditional machining processes. WEDM process is based on the conventional EDM sparking phenomenon utilizing the widely accepted non-contact technique of material removal. Since the introduction of the process, WEDM has evolved from a simple means of making tools and dies to the best alternative of producing micro-scale parts with the highest degree of dimensional accuracy and surface finish quality. This author reviews the vast array of research work carried out from the EDM process to the development of the WEDM, also highlights the working principle and mechanical performance of machining conditions. A wide range of WEDM industrial applications are reported together with the development of the hybrid machining processes. The final part of the paper discusses these developments and outlines the possible trends for future WEDM research.

• Periodical: Advanced Materials Research (Volume 507)
• Pages: 180-183
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.507.180
• Online since: April 2012
• Authors: Cun Shan Xu
• Keywords: Industrial Application, WEDM, Working Principle

References

[1] K. H Ho, S. T Newman, S Rahimifard. State of the art in wire electrical discharge machining (WEDM). International Journal of Machine Tools and Manufacture. Volume 44, Issues 12-13, 2004, P1247-1259.

DOI: 10.1016/j.ijmachtools.2004.04.017

[2] Norliana Mohd Abbas, Darius G. SolomonMd. A review on current research trends in electrical discharge machining (EDM). International Journal of Machine Tools and Manufacture, Vol 47, Issues 7-8, June 2007, P1214-1228.

DOI: 10.1016/j.ijmachtools.2006.08.026

[3] Masanori Kunieda, Chika Furudate. High Precision Finish Cutting by Dry WEDM. CIRP Annals - Manufacturing Technology. Volume 50, Issue 1, 2001, P121-124.

DOI: 10.1016/s0007-8506(07)62085-x

[4] K. H. Ho, S. T. Newman. State of the art electrical discharge machining (EDM). International Journal of Machine Tools and Manufacture, Vol 43, Issue 13, October 2003, P1287-1300.

DOI: 10.1016/s0890-6955(03)00162-7

[5] Mu-Tian Yan, Chen-Wei Huang, Chi-Cheng Fang. Development of a prototype Micro-Wire-EDM machine. Journal of Materials Processing Technology, Vol 149, Issues 1-3, 10 June 2004, P99-105.

DOI: 10.1016/j.jmatprotec.2003.10.057

[6] SeongMin Son, HanSeok Lim, A.S. Kumar. Influences of pulsed power condition on the machining properties in micro EDM. Journal of Materials Processing Technology, Volume 190, Issues 1-3, 23 July 2007, P73-76.

DOI: 10.1016/j.jmatprotec.2007.03.108
