Prediction of Ice Accretion on Wind Turbine with Numerical Method

Abstract:

A three dimensional numerical method and its computer codes, which are suitable to predict the process of horizontal axis wind turbine icing, are presented. The method is composed of the Multiple Reference Frame (MRF) method to calculate flowfield of air, an Eulerian method to compute collection efficiency and a three dimensional icing model companying with an iterative arithmetic for solving the model. Ice accretion on a 1.5 MW horizontal axis wind turbine is then computed with the numerical method, and characteristics of droplet collection efficiency and ice shape/type are obtained. The results show that ice on the hub and blade root is slight and it can be neglected comparing with ice near blade tip. From blade tip to root, ice becomes thinner and glaze ice may changes into rime ice.
