A New Design of the High-Skew Ducted Propeller

Abstract:

Unmanned Underwater Vehicle (UUV), which could be used for ocean exploration and development, developed rapidly in recent years. In order to make UUV quieter to be competent for rigorous working conditions, a new propulsion with lower underwater noise must be designed. A new high-skew ducted propeller, which had the advantages of both ducted propeller and high-skew propeller, had been designed for UUV to obtain adequate thrust and lower underwater noise. CFD simulation of the high-skew ducted propeller showed that the thrust was enough for UUV working underwater and the hydrodynamic efficiency was very close to that of conventional ducted propeller. The strength of high-skew ducted propeller had been checked by FEM method, and the maximum stress would appear on the trailing side of blade on 0.5R, where the blade was unsubstantial. Underwater noise had also been measured, which proved that the high-skew ducted propeller had lower noise than that of conventional ducted propellers. As a quiet propulsion, the high-skew ducted propeller could be used on UUV or ship who want to be quiet underwater.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1048-1052
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1048
• Online since: May 2012
• Authors: Bin Fang, Min Lei, Qi Dou Zhou
• Keywords: Computational Fluid Dynamics (CFD), Ducted Propeller, Finite Element Method (FEM), High-Skew Propeller, Underwater Noise, Unmanned Underwater Vehicle (UUV)

References

[1] A. Sanchez-Caja, P. Rautaheimo, T. Siikonen: Simulation of the incompressible viscous flow around a ducted propeller using a RANS equation solver, Proceedings of the 23rd Symposium on Naval Hydrodynamics, edtied by Office of Naval Research, Bassin d'Essais des Carenes and National Research Council, Val de Reuil, France (2000).

[2] Daqing Li: Validation of RANS predictions of open water performance of a highly skewed propeller with experiments, Proceedings of the Conference of Global Chinese Scholars on Hydrodynamics, edtied by Shanghai University Press, Shanghai, China (2006).

DOI: 10.1016/s1001-6058(06)60106-6

[3] W. G. Park, Y. R. Jung, C. K. Kim: Ocean Engineering, Vol. 32(2005), pp.1260-1277.

[4] ChaoWang, Sheng Huang, Xueshen Xie: Journal of Naval University of Engineering, Vol. 20 (2008), pp.107-112. (in Chinese)

[5] Xiaojun Lv, Qidou Zhou, Gang Ji, et al: Journal of Naval University of Engineering, Vol. 22 (2010), pp.24-30. (in Chinese)

[6] Yong Zhang, Ersheng Cheng: The FEM research on the stress of high-skew propeller, Proceedings on Naval Architecture and Ocean Engineering, edtied by Huazhong University of Science and Technology Press, Wuhan, China (2001). (in Chinese)

[7] Xianghui Yang, Ersheng Cheng: Naval Architecture and Ocean Engineering, Vol.158(2004), pp.6-9. (in Chinese)

[8] Tongbing Gao, Ersheng Cheng: Naval Architecture and Ocean Engineering, Vol.159(2004), pp.1-3. (in Chinese)
