Numerical Study on Coupled Heat Transfer of Thrust Chamber with Raised Structure

Abstract:

By the use of the map of the thermal resistance among volume cells, we establish a coupled heat transfer model of the hot gas, chamber wall and coolant. A reduced one-dimensional model was employed for the coolant flow and heat transfer, and three dimensional heat transfer model was used to calculate the coupling heat transfer through the wall, considering heat transfer at circumferential direction, axial direction and radial direction. Based on the study the mechanism of the cooling structure heat transfer, the computing model was employed and achieved the rule of heat flux and temperature of gas wall. Simultaneously, influence of different cooling structure was performed. The results indicated that the cooling structure with raised structure could better reduce the temperature of the chamber wall.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 107-110
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.107
• Online since: May 2012
• Authors: Tao Nie, Wei Qiang Liu
• Keywords: Cooling Structure, Coupled Heat Transfer, Finite Volume Method (FVM), Numerical Simulation, Thrust Chamber

References

[1] M H Naraghi. AIAA 88-2643, 1988.

[2] Wang T S, Luong V. AIAA 92-3151,(1992)

[3] Li Junwei, Liu Yu. Journal of Aerospace Power, 2004, 19(4):550-556(in chinese)

[4] Liu Weiqiang, Jiangchunlin, et al. Journal of National University of Defense Technology, 1999, 21(2): 13-16(in chinese)

[5] Guo Zhaoyuan, Wang Qiang, Feng Guotai. Acta Aeronautica et Astronautica Sinica, 2005, 26(2): 111-115(in chinese)

[6] D. R. BARTZ. Jet Propulsion ,January (1957)

[7] Jiang Jin, Zhang Ruoling, Le Jialing. Journal of Aerospace Power, 2009, 24(12):2649-2654 (in chinese)

[8] Zhang Xiaoying, Cai Guobiao, Zhu Dingqiang. Journal of Aerospace Power, 2008, 23 (1) :195-200(in chinese)
