Electric Field Analysis of 220 kV Composite Material Tower Lines

Abstract:

Using the finite element analysis, this work analyzed the electric field distribution of 220kV transmission steel tower with double-circuit and composite material transmission tower with the same size, and compared the electric field effect of two materials transmission tower for surroundings. And this work compared the vertical and axial electric field distribution along transmission line of the two materials transmission tower. The results indicate the composite material tower can improve the environment of electric field near the transmission lines.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1517-1520
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1517
• Online since: May 2012
• Authors: Jian Xun Hu, Gong Da Zhang, Hong Yu Zhang, Xiao Qin Zhang
• Keywords: Composite Material Tower, Electric Field Distribution, Finite Element, Transmission Line

References

[1] Transmission and Distribution Committee．IEEE guide for application of composite line post insulators (New York: 2004).

[2] W. H. Hayt: Engineering electromagnetic (The McGraw-Hill Publishing, Washington, USA 2006)．

[3] Shutang Liu: Transmission Tower Structure and Basic Design. In Chinese (China Water Power Press, Beijing, China 2005)．

[4] Xun Jiang, Zhongyi Wang, Qiang Jin: High Voltage Apparatus, 2005, 41(5)：340-342.

[5] Daochun Huang, Jiangjun Ruan, Jia Liu: High Voltage Engineering, 2007, 33(1): 91-94.

[6] Yao Lu, Xiong Wu, Baoquan Wan: High Voltage Engineering, 2006, 32(12): 66-68, 82.
