Thermal and Stress Field Analysis in Heavy-Duty Gas Turbine Exhaust System

Abstract:

Heavy-duty gas turbine is used widely in power generation industry for many advantages. Gas turbine exhaust system is an important component of the gas turbine. The work to study the exhaust system was less in the past. In fact, structure design of the exhaust system has important influence on performance and life of the gas turbine. In this paper, the three-dimensional structural model of gas turbine exhaust system is built, the thermal field and stress field for the exhaust system are analyzed by using finite element method (FEM). The maximum stress and distribution characteristics of stress field, the highest temperature and distribution characteristics of thermal field in the exhaust system are computed. These provide a reliable basis for reasonable design and safety evaluation of the exhaust system in gas turbine.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 688-691
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.688
• Online since: May 2012
• Authors: Rui Zhu, Jian Xing Ren, Fang Qin Li, Hong Du Zhang, Yun Tang
• Keywords: Exhaust System, FEM Analysis, Heavy-Duty Gas Turbine, Stress Field, Thermal Field

References

[1] Rui Zhu, Jianxing Ren, etc. Advanced Materials Research, Vol. 354 (2012), p.483

[2] M. Pinelli, G.Bucci. Applied Energy. Vol. 86 (2009), P857

[3] Zachary JJ. Strategies for integration of advanced gas and steam turbines in power generation applications. ASME Paper GT2007-27978.

[4] Haiying Zheng, Guirong Ding. Boiler Technology, Vol. 41(2010), p.10(In Chinese)

[5] Shihang Zhao: Gas turbine structure. (Tsinghua University Publishers，1983) (In Chinese)

[6] Xiuping Yao: Gas turbine and combined cycle power generation.(China Electric Power Press，2004) (In Chinese)
