Study on Method and Experiment of Characteristics Impedance Calculation of Elastic Bars Based on Incident Wave and Reflected Wave

Abstract:

Characteristics impedance is a very important physics parameter for many applications in rock fragmenting and percussive drilling. When the shape of the elastic bar is very complicate, it is difficult to calculate the characteristics impedance of the elastic bar with its definition. A method which uses the incident wave and reflected wave to calculate the characteristics impedance of elastic rods is presented. Firstly, the relationship of the incident wave, reflected wave and the characteristics impedance of elastic rods is studied on the basis of the reflection and transmission laws of elastic waves and, the resolution model is established; Then impact experiments were carried out in which a drilling bit with step cross-section was designed. The signal processing of eliminating polynomial trend item and discrete wavelet de-noising were done to stress signals before calculation to decrease the error. It is proved that the method is adequately accurate from the testing results.

• Periodical: Advanced Materials Research (Volumes 518-523)
• Pages: 3784-3791
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.518-523.3784
• Online since: May 2012
• Authors: Kai Duan, De Shun Liu, Chang Yue Sun, Zhi Gao Yang
• Keywords: Characteristics Impedance Calculation, Discrete Wavelet De-Noising, Incident Wave and Reflected Wave Eliminating Polynomial Trend Item

References

[1] D.S. Liu, X.B. Li and P.Y. Zhu, in: Dynamics and Inverse Design of Impact Machines, edited by Science Press, Beijing (2007), in press. In Chinese.

[2] B. Lundberg, J. Garlsson and K. G. Sundin: Journal of Sound and Vibration Vol. 137(1990), pp.483-493.

[3] B. Lundberg, A. Henchoz: Experimental Mechanics Vol. 17(1977), pp.213-218.

[4] B. Lundberg: Int. J. Rock Mech. Min. Sci. & Geo. Abstract Vol. 19(1982), pp.229-239.

[5] B. Lundberg: Int. J. Rock Mech. Min. Sci. & Geo. Abstract Vol. 22(1985), pp.237-249.

[6] J. Carlsson, K. G. Sundin and B. Lundberg: International Journal of Rock Mechanics Mining Science & Geomech Vol. 27(1990), pp.553-558.

[7] Q.H. Jiang, Y.M. Wu: Engineering Journal of Wuhan University Vol. 36(2003), pp.22-25. In Chinese.

[8] B. Lundberg, P. Collet: International Journal of Impact Engineering Vol. 37(2010), pp.901-906.

[9] M.Z. Sun: Instrumentation Analysis Monitoring Vol. 1(2007), pp.11-12. In Chinese.

[10] X.L. Liu, X.B. Li, L. Hong, et al: Explosion and Shock Waves Vol. 29(2009), pp.67-72. In Chinese.
