Research and Development of the Quick Mapping System on Rural Planning

Abstract:

The rural users have little knowledge on the professional planning map. So current many professional mapping systems are not suitable for these users. In order to help the rural users make and use the planning map themselves, a quick mapping system on rural planning and relative mapping methods are proposed in this work. The two core methods are the generation and classification method on the map symbol of the rural features and the visual disposal method on the rural planning flow. These new methods depress the complexity of the mapping and planning disposal. Based on these methods, the users with low computer skills can make digital map and planning. A quick mapping system on rural planning is developed by integrating the new methods. The system provides four core functions, i.e. Protract the planning map of the rural features, Generate map symbol with a wizard, Customize the planning flow and Dispose the planning business by the flow and display the village with 3D scene. Many rural planning maps produced by the software indicates that the software can improve the management efficiency of village theme inform action with certain degree.

• Periodical: Advanced Materials Research (Volumes 518-523)
• Pages: 5729-5733
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.518-523.5729
• Online since: May 2012
• Authors: Hua Ji Zhu, Hua Rui Wu
• Keywords: Map Symbol, Planning Flow, Quick Mapping, Rural Planning, Visual Customization

References

[1] Liao K. Modern Cartology. Beijing: Science Press, 2003.(In Chinese)

[2] Ling S.J. Cartography, 1997(4):3-4. (In Chinese)

[3] Xu H.Y., Shi Y., Zhou X.H. Computer Science, 2000, 27 (1): 80-84. (In Chinese)

[4] Chen Y.F. Beijing Surveying and Mapping,1998(1):37-39.(In Chinese)

[5] Dent B D. Cartographic Thematic Map Design. Reading: Addison-Wesley, 1999, 16.

[6] Tan X.J., Bian F.L., He Z.H. Bulletin of Surveying and Mapping, 2003(1):11-13. (In Chinese)

[7] Wang W., Zhang B., Yin G.H. Geomatics And Information Science of Wuhan University, 2002, 27(3):296 - 300. (In Chinese)

[8] Yuan K.S, Zhang R.Q., Wang Y.J. Geo-information Science, 2007, 9( 8): 100 -107. (In Chinese)

[9] Cheng P.G., Gong J.Y., Sui H.G. Journal of Image and Graphics, 2000, 5(A)(12):1006-1011. (In Chinese)

[10] Ling Y., Chen Y.F., Wang Y.J. Journal of Institute of Surveying and Mapping, 2005, 22(1):69-75. (In Chinese)

[11] Yang C.C., Song Z.G., Wu W.H. Science of Surveying and Mapping, 2002, 27(1):50 - 53. (In Chinese)

[12] Cai Z.L., Li L. Geomatics and Information Science of Wuhan University, 1999,24 (3):259-261. (In Chinese)

[13] Li T.H., Xue A., Yang H.H.. Bulletin of Surveying and Mapping, 1998, (3):10-13. (In Chinese)
