Reinforcing Analysis for the Lower Chord of Steel Truss Bridge Based on Thermosetting Resin Matrix Composite

Abstract:

Thermosetting resin composite material has been widely used in strengthening the concrete members. However, there are only a few applications in strengthening steel structure. Based on the finite element analysis software ANSYS in this article, mechanical analysis are carried out for the lower chord before and after reinforcement of the long-span steel truss bridge and comparison are made. Interlaminar stresses in X, Y, Z three directions of the composite laminates are extracted. Compared with the results, the conclusion that application of composite materials for reinforcement of the lower chord can change the stress of the lower chord and improve the quality of the steel trussed bridge is drawn out.

• Periodical: Advanced Materials Research (Volume 531)
• Pages: 589-592
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.531.589
• Online since: June 2012
• Authors: Jia Guo Zheng, Yun Shu Zhao, Yue Ping Zhao, Qi Jun Chen
• Keywords: ANSYS, Composite Material, Finite Element, Lower Chord, Reinforcement

References

[1] . Ren Tao. The elastic buckling and limit load of I-beam under partial bearing pressure and shearing force [D]. Hangzhou: Zhejiang University, (2005).

[2] Wu Z J. Davies J M. Mechanical Analysis of a Cracked Beam Reinforced with an External FRP Plate[J]. Composite Structure. 2003, 62: 139-143.

DOI: 10.1016/s0263-8223(03)00108-9

[3] Abushaggur M, Damatty ED. Testing of Steel, Section Retrofitted Usi ng FRP Sheets[R]. Annual Conference of the CanadianSocietyforCivilEngineering. Canada: Moncton, Nouveau Brunswick (2003).

[4] Tian X F, et al. A Numberical Three-dimensional Model for the Contact of Rough Surfaces by Variational Principle [J]. ASMEJ of Trib, 1996, 200: 265~280.
