The Research on Slices’ Data Repair and Filling Path Optimization

Abstract:

Fused deposition modeling (FDM) is one of rapid prototyping process, which process includes Common Layer Interface (CLI) file generation and rapid prototyping. This paper focuses on algorithm to repair error datum of slices to generate CLI file and arithmetic-zoning scanning algorithm based intersection sorting which were used to FDM process. Conclusions of experiment show that the algorithm to repair error datum of slices can correct repair the error datum and fast extraction of contour information, and it provides an efficient method for generating CLI file from Stereo lithography(STL) slices; that arithmetic-zoning scanning method can reduce the possibility of model wrapping and shrinkage stress. The two algorithms improve production efficiency of FDM and are worth promoting.

• Periodical: Advanced Materials Research (Volumes 532-533)
• Pages: 1060-1063
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.532-533.1060
• Online since: June 2012
• Authors: Gen Song Zhu, Wei Xu, Zhi Feng Xu
• Keywords: Common Layer Interface, Deposition Modeling, Rapid Prototyping (RP), Stereo Lithography

References

[1] D M C Santos, A E M Pertence, P R Cetlin. The development of 3D models through rapid prototyping concepts[J]. Journal of Materials Processing Technology, 2005. 168: 270~272.

DOI: 10.1016/j.jmatprotec.2005.02.220

[2] Haipeng Pan, Tianrui Zhou. Generation and optimization of slice profile data in rapid prototyping and manufacturing[J]. Journal of Materials Processing Technology, 2007. 187-188: 623~62.

DOI: 10.1016/j.jmatprotec.2006.11.221

[3] Haipeng Pan, Tianrui Zhou. Research on the Algorithm for Generating the Slicing Profile of STL Model[J]. China Mechanical Engineering, 2007. 18(17): 2076~(2078).

[4] K F Leong, C K Chua , Y M Ng. A Study of Stereo lithography File Errors and Repairs Generic Solution[J]. Part 1, International Journal of Advanced Manufacturing technology, 1996, 12: 407~414.

DOI: 10.1007/bf01186929

[5] Liu Bin Xiao Yuejia Han Ming. On an Algorithm for Automatic Recognition of the Boundaries inside and outside a Solid Cross-Section Contour [J]. J Huazhong univ of Sci & Tech, 1996 , 24 (10): 23~25.

[6] ZHANG Yong, ZHOU Tian-rui, ZHONG Xue-hu etc. Optimization and simulation on filling path in FDM rapid prototyping process[J]. Forging and Stamping Technology, 2008, 4(33): 124~127.

[7] Asiabanpour B, Khoshnevis B. A new memory efficient tool path generation method for applying very large STL files in vector-by-vector rapid prototyping processes [A]. Computers and Industrial Engineering Conference [C]. San Francisco, CA, (2003).

[8] Bahram Asiabanpour , Behrokh Khoshnevis. Machine path generation for the SIS process [J]. Robotics and Computer Integrated Manufacturing, 2004, 20 (3): 167-175.

DOI: 10.1016/j.rcim.2003.10.005
