The Redevelopment of Matrox Meteor-II/Digital Image Grabbing Board with VC++

Abstract:

In order to store real-time images, a digital image grabbing system is proposed in this paper. The principles and design of real-time image continuous grabbing, displaying and storing system are presented. It has been redeveloped based on Matrox Meteor-II /Digital Image Grabbing Board by the use of VC++, and the whole implementation was introduced by an example. The developed image capture software is given at the end of this paper. And this gives a new thought and platform for real-time image processing.

• Periodical: Advanced Materials Research (Volumes 532-533)
• Pages: 1152-1156
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.532-533.1152
• Online since: June 2012
• Authors: Cai Fang Liu, Bing Liang Hu, Cai Ling Wang, Lei Liu
• Keywords: Continuous Image Grabbing, Image Grabbing Board, Real-Time Image Storing, Redevelopment

References

[1] LEI Xiao-feng, WANG Yao-nan, DUAN Feng. Microcomputer and Its Applications, Vol 21(2002), p.44.

[2] Matrox Electronic Systems Ltd . Matrox Meteor-II/Digital installation and hardware reference. CANADA (2002).

[3] JI Zhi-hong, LIU Xiao-ping. Instrumentation Technology, Vol 1(2008), p.32.

[4] LI Yan-ni, CHEN Ping, WANG Xian-qing. C++ Programming Language, Xi'an: XiDian Press(2009).

[5] ZHENG Li, DONG Yuan. C++ Programming Language. Beijing：Tsinghua University Press(2001).

[6] HUANG Wei-tong. Visual C++. Beijing：Tsinghua University Press(2002).
