Theory Study and Numerical Analysis of Ultra-Thin Wall Injection Molding

Abstract:

The article focuses on the discussion of size relationship of melt viscosity of ultra-thin wall injection molding, revising the viscosity model of traditional stimulant Cross-WLF. It takes the theory of Uhland wall-slip, trying to analyze the influence which the wall-slip of the molding makes on injection molding. It also points out the limitation of constant heat transfer coefficient in the molding. The change rules of the heat transfer coefficient is among the study. Using the method of numerical simulation and experience, the article verifies the consistency of experience result and the change of the factors, such as using ultra-thin viscosity model, wall-slip and the change of heat transfer coefficient while doing the simulation.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 1145-1153
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.1145
• Online since: June 2012
• Authors: Su Feng Yin, Feng Ruan, Jian Yu Wang
• Keywords: Molding, Numerical Simulation, Theoretical Modeling, Ultra-Thin Wall Injection

References

[1] Fassett J．Thin- wall molding．How its Processing considerations differ from standard Injection molding[J]．Plastics Engineering．1995，51(12)：35-37．

[2] Guojun Xu．Study of thin-wall injection molding[D]．The Ohio State：The Ohio State University，2004．

[3] Sufeng Yin， Jianyu Wang， Feng Ruan．Impact on PC light guide plate warpage caused by injection parameters [C]， International Conference on Digital Manufacturing & Automation, 2010．12．

DOI: 10.1109/icdma.2010.162

[4] Qiye Wu．Polymer Rheology [M]．Beijing：China Higher Education Press，2002．

[5] ISRAELACHVILI J N．Measurement of the viscosity of liquids in very thin films[J] ．Journal of Colloid Interface Science，1986， 110 (11)：263-271 ．

DOI: 10.1016/0021-9797(86)90376-0

[6] Fei Yetai．Error Theory and Data Processing [M]．Beijing：China Machine Press，2007．7．

[7] Jun Tang．Considering the elasticity of the melt wall slip on the micro scale flow effects [J]．China Mechanical Engineering 2009.6

[8] Awati K M，Park Y，Weisser E et al．Wall slip and shear stresses of polymer melts at high　Shear rates without Pressure and viscous heating effects[J]： Journal of Non－Newtonian Fluid Mechanics，2000，89(1-2)：117－131．

DOI: 10.1016/s0377-0257(99)00037-3

[9] Yu L Y，Lee L J，Koelling K W． Flow and heat transfer simulation of thin－wall injection molding with microstructures[J]．SPE ANTEC Technical ，2003．

[10] Boddington T， Feng C G，Gray P．Thermal explosions　criticality and transition in systems with variable heat transfer coefficient [J]． Journal of the Chemical Society Faraday TransactionsⅡ， 1983，79(10)：1481-1498．

DOI: 10.1039/f29837901481

[11] H. K. Lee, J. C. Huang, G . E. Yang, H. G. KimFar .Analysis of Residual stress in Thin Wall Injection Molding[C]． 6th International Conference on Fracture and Strength of Solids ．2005.1

[12] Wimberger-Friedl R． The assessment of orientation ,stress and density distributions in injection molded amorphous polymers by optical techniques[J]．Prog Polym Sci，1995，20：369

DOI: 10.1016/0079-6700(94)00036-2
