Study on the Surporting Mechanism of Precision Turning Process of Big-Diameter Length Rate Shaft by the Central Frame

Abstract:

Deformation of the big-diameter length rate shaft and turning process control mechanism were studied. When it was supported by the central frame, its theoretical mechanics models were established. Based on probability theory, considering the randomness of cutting force, elastic modulus, its length and its diameter, its theoretical model was established to calculate its standard deviation of the roundness. Moreover, its dynamic response finite element model was established, and the model was verified through comparison with the theoretical calculation results. The study provides the method and theoretical basis for the precision turning process planning of the big-diameter length rate shaft.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 2139-2142
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.2139
• Online since: June 2012
• Authors: Guo Zhi Zhang
• Keywords: Big-Diameter Length Rate Shaft, Central Frame, Dynamic Response, Finite Element Method (FEM), Precision Turning Process, Probability Theory

References

[1] Zhao Zhiping, Li Xinyong. Mechanical Research &Application, Vol 17 No. 4, (2004), p.43～44 (in Chinese)

[2] Zhang Mingjun, Yin Guofu, Yuan Guanghui. Chinese Journal of Mechanical Engineering, Vol 41 No. 2, (2005), p.137～141 (in Chinese)

[3] Liu Peiyue, Yan Zhibo. Journal of Shijiazhuang Vocational Technology Institute, Vol 21 No. 4, (2009), p.24～26 (in Chinese)

[4] Domenico Umbrello. Journal of Materials Processing Technology, Vol 196 No.1-3, (2008), p.79~87

[5] Wen Xiaoshuo, Wang Keqi. Tool Engineering, Vol 40 No. 7, (2006), p.31～32 (in Chinese)

[6] Li Kunshu, Meng Zhaoming. Machine Tool & Hydraulics, Vol 37 No. 9, (2009), p.39～41 (in Chinese)
