Single-Phase Double-Stage PV Grid-Connected System Based on Multi-Carrier PWM

Abstract:

In the traditional single-phase grid-connected photovoltaic(PV) system, the output grid-current has the shortcoming of high harmonic distortion rate. In order to solve the problem, an improved method on the inverter is proposed. The inverter consists of full-bridge circuit and auxiliary circuit. With the multi-carrier PWM, the inverter produces output voltages in five levels, which can reduce the THD of the grid current. At the same time, the hysteresis comparison method is introduced into traditional MPPT algorithm, which greatly avoids the oscillation problem of the maximum power point. At last, the simulation results show the effectiveness of the proposed method.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 1231-1237
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.1231
• Online since: June 2012
• Authors: Guo Shun Zhou, Ye Jin Lin, Yan Cheng Liu, Qin Jin Zhang
• Keywords: Grid-Connected PV Inverter, Hysteresis Comparison Method, Maximum Power Point Tracking (MPPT), Multi-Carrier PWM Technology

References

[1] YAN Huimin, ZHOU Zhizhi，LU Huayong．Photovoltaic industry and market investigation. 1st Conference on Sustainable Power Generation and Supply, SUPERGEN 2009. Nanjing, China: IEEE, 2009: 1-4．

DOI: 10.1109/supergen.2009.5348104

[2] Ersoy Beser, Birol Arifoglu, Sabri Camur, Esra Kandemir Beser. A grid-connected photovoltaic power conversion system with single-phase multilevel inverter. Solar Energy, 2010, 84: 2056-2067.

DOI: 10.1016/j.solener.2010.09.011

[3] Agelidis VG, Baker DM, Lawrance WB, Nayer CV. A multilevel PWM inverter topology for photovoltaic application. Proceeding of IEEE ISIE'97 1997,2:589-594.

DOI: 10.1109/isie.1997.649027

[4] XIAO Huafeng, YANG Chen, XIE Shaojun. A Transformerless PV Grid-connected Inverter Based on Improved Full Bridge Topology. Proceedings of the CSEE,2011,31(3):40-45.

[5] Jaime Alonso-Martinez, Joaquin Eloy-Garcia, Santiago Arnaltes. Direct power control of grid connected PV systems with three level NPC inverter. Solay Energy, 2010,84:1175-1186.

DOI: 10.1016/j.solener.2010.03.023

[6] Woo-Young Choi, Jih-Sheng(Jason) Lai. High-efficiency grid-connected photovoltaic module integrated converter system with high-speed communication interfaces for small-scale distribution power generation. Solar Energy,2010,84:636-649.

DOI: 10.1016/j.solener.2010.01.004

[7] ZHOU Lin, WU Jian, LI Qiu-hua, etc. Survey of Maximum Power Point Tracking Techniques for Photovoltaic Array. High Voltage Engineering, 2010,30(6):16-19.

[8] Esram T. Chapman PL. Comparison of photovoltaic array maximum power point tracking techniques. IEEE Transactions on Energy Conversion, 2007:22(2):439-449.

DOI: 10.1109/tec.2006.874230
