Research on Automatic Generation Technology of Structural Net and Speed Diagram

Abstract:

In view of the teaching problems and difficulties of machinery manufacturing equipment design, the automatic generation technology of structural net and speed diagram was proposed. The conceptions and characteristics of structural formula, structural net and speed diagram were discussed. The expected targets of the automatic generation technology were put forward. The technical principles of automatically generating structural net and speed diagram were respectively analyzed. Based on these, the automatic generation software of structural net and speed diagram was designed and developed. The development environment and implementation methods of the software were proposed. It is proved that the software can play an important role in improving the teaching effect and quality.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 1422-1425
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.1422
• Online since: June 2012
• Authors: Li Li, Zhao Yun Wu
• Keywords: Automatic Generation Technology, Main Transmission System, Speed Diagram, Structural Net

References

[1] J.H. Jiang, X.Y. Wang, J. Zhang and W.P. Yang: Manufacturing Technology and Machine, (2000) No.8, pp.11-13. (In Chinese)

[2] K. Huang, T.J. Li and F.R. Tian: Machine and Hydraulic, (1999) No.4, pp.47-48. (In Chinese)

[3] X. Feng: Machinery manufacturing equipment design (China Machine Press, China2009). (In Chinese)

[4] J.L. Kang and Z.Q. Wu: Computers and Applied Chemistry, Vol. 26 (2009), pp.763-766.

[5] H.S. Wang, C.F. Wu and Y.Z. Gao: China Plastics, Vol. 15 (2001), pp.83-86. (In Chinese)
